SolarEdge RS485 Plug-in User Manual

D e v i c e T y p e < S E >
P r o t o c o l < S >
D e v i c e I D < 1 >
D i s a b l e
7.
The default protocol is slave. To configure as master select
Protocol è Master.
The Slave Detect and Slave List menus are added to the
screen.
D e v i c e T y p e < S E >
P r o t o c o l < S >
D e v i c e I D < 1 >
S l a v e D e t e c t
S l a v e L i s t
D i s a b l e
8.
Select Slave Detect.
The system starts automatic detection of the SolarEdge
slave devices connected to the master device. The master
device should report the correct number of slaves. If it does
not, refer to the RS485 troubleshooting section below.
Troubleshooting
Troubleshooting RS485 Communication
1. If the message Master Not Found appears, check the
connections to the master device and fix if required.
RS485 Expansion Kit Installation Guide MAN-01-00258-1.0
19 Troubleshooting

SolarEdge RS485 Plug-in Specifications

General

Communication Interface	RS485
Compatibility	SolarEdge inverters
Installation	Plug-in
Category	Cables and connectors
Plug-in Type	RS485
Purpose	Communication between SolarEdge inverters and monitoring systems
Function	Communication
Compatibility with Monitoring Systems	Compatible with SolarEdge monitoring systems
