Color Status Indication
Fast blinking
(5 sec.)
During pairing of repeater
and uplink gateway, and
Pairing between the repeater
and the Wi-Fi Gateway or the
closest uplink repeater to the
inverter succeeded.
Blinking
Communication between the
Wi-Fi Gateway and the
monitoring platform is OK,
and
No communication between
the Wi-Fi Gateway/repeater
and the downlink repeater/
inverter
Orange
Fast blinking
(5 sec.)
Pairing of a repeater with the
Wi-Fi Gateway or the closest
uplink repeater failed
Blinking
No communication between
the Wi-Fi Gateway/repeater
and the monitoring platform,
and
Wi-Fi Gateway and Repeater Installation Guide MAN-01-00559-1.1
16 LEDIndications
