The Wi-Fi Gateway and repeater can be used with SolarEdge
inverters with SetApp configuration, version 4.6.xx and later.
Figure 1: The Wi-Fi Gateway/ Repeater
Connection Options
Terminology
This document uses the following terms for describing the
communication flow:
Uplink - communication from the inverter or Wi-Fi
repeater to the Wi-Fi Gateway/repeater towards the
monitoring platform (see
Figure 2
).
Downlink - communication from the Wi-Fi Gateway or
repeater towards the inverter/ repeater (see
Figure 2
).
Wi-Fi Gateway and Repeater Installation Guide MAN-01-00559-1.1
10 Connection Options
