SolaX Power X1-Hybrid-3.7-D Installation Manual

61
PV Connection / PV-Anschluss / Connexion PV / Conexión FV / Ligação PV
(Fotovoltaica) / PV-aansluiting / Collegamento PV / Połączenie PV / Připojení FV
/ Anslutning av solcellsanläggning / Conexiune PV /

PV /
PV-tilslutning
/

/
PV-ühendus / PV-liitäntä / Fotonaponski priključak / PV
bekötés / Fotovoltinė jungtis / PV savienojums / Pripojenie fotovoltaiky (FV) / Povezava
fotonapetostnega kabla (PV) / PV bağlantısı / Conexão fotovoltaica /

The PV port wiring of M series has been completed on X1-Matebox, the D series needs to
be wired according to the following steps.
1
4 mm
7 mm
+
-
+
+
-
-
Crimping tool for PV terminal
2
Click!
Click!
+
-
+
-
+
-
3 4
≤600 V
