SolaX Power X3-PRO G2 Series User Manual

44 45
Operation MethodOperation Method
Ø Menu interface
The menu interface (Level 2) is a transfer interface for the user to get into
other interface to finish the setting or get the information.
-User can get into this interface by long pressing “Down” button when LCD
displays the main interface.
-User can select by moving the cursor with function button, and long press
“Down” to confirm.
Ÿ Status
The status function contains two aspects, the grid and the solar.
Press ”Up“ and “Down” to select and long press “down” to confirm the
selection, long press “Up” to return to Menu.
a) Grid
This status shows the current grid condition such as voltage, current,
output power and grid power. Pout measures the output of the inverter,
Pgrid measures power export to or import from grid. Positive value means
the power feeds into grid, negative value means the power used from the
grid.
Press ”Up“ and “Down” button to review the parameter, long press “up” to
return to Status .
Power 0W
Normal
Status
Language
Grid
Solar
Status
﹦﹦ ﹦﹦
Menu
﹦﹦ ﹦﹦
﹦﹦ ﹦﹦ ﹦﹦ ﹦ ﹦
Ø LCD Digital Display
The main interface (Level 1) is the default interface, the inverter will
automatically jump to this interface when the system started up successfully
or not operated for a period of time.
The interface shows the following information. “Power” means the timely
output power; “Pgrid” means the power export to or import from the grid;
(Positive value means the energy feeds into the grid, negative value means
the energy used from the grid); “Today” means the power generated within
the day; “Total” means the power generated until now.
Press ”Up“ and “Down” to review the information.
b) Solar
This status shows the real time PV condition of the system, such as
input voltage, current and power situation of each PV input.
Press ”Up“ and “Down” button to review parameter, long Press “Up” to return to
Status.
Solar
U1 0.0V
I 1 0.0A
Grid
Ua
0
.0 V
Ia 0.0A
Ÿ Language
The function refers to select a language from English, German, Polish, French,
Portuguese, etc.
Language
English
Ÿ Date Time
This interface is for the user to set the system date and time. Increase or
decrease the word by pressing “Up” or “Down” button. Press “Down” to confirm
and alternate to next word. After all the words are confirmed. Long press
“Down” to enter the date and time.
Date Time
>2021- 01 -01
00:00
*
*
*
*
﹦﹦ ﹦﹦ ﹦﹦ ﹦﹦
﹦﹦ ﹦﹦ ﹦﹦ ﹦﹦
﹦﹦ ﹦﹦ ﹦﹦ ﹦﹦
German
﹦﹦ ﹦﹦ ﹦﹦ ﹦ ﹦
