Solax X3 series User Manual

l) Load Reset
Reset consume is to reset load, user can reset the load if the inverter is plugged
in a smart plug. Press up or down button to select and press “ok” to confirm.
m) Meter Reset
User can reset the meter. Press up or down button to select and press “ok” to
confirm. (User can Select “Yes” to reset meter if user purchase SolaX meter)
n) Errorlogs Reset
User can reset the error log here. Press up or down button to select and
press “OK” to confirm.
﹦﹦ ﹦
Reset
No
o) Start guide
This interface makes user set initial setting of the inverter again possible.
﹦﹦ ﹦ Load Reset ﹦﹦ ﹦ ﹦
Load 1 Reset
>No<
﹦﹦ ﹦Meter Reset ﹦ ﹦ ﹦ ﹦
Reset
>No<
﹦﹦ ﹦
Start guide
﹦﹦ ﹦
38 39
Operation MethodOperation Method
Errorlogs Reset ﹦﹦ ﹦
>Start
● History
The history function contains four aspects of the information: Inverter yield, load
consume, Meter and error logs.
Press up and down to select ,and press “OK” to confirm the selection, press
“ESC” to return to Menu.
a) Inverter Yield
The inverter yield function contains energy generated by today, yesterday ,this
month ,last month and total.
Press up and down button to review the parameter, Press “ESC” to return to
history.
﹦﹦ ﹦ ﹦ History ﹦ ﹦ ﹦ ﹦
>Inverter Yield
Load consume
﹦﹦ ﹦ ﹦
Inverter Yield
﹦﹦ ﹦ ﹦
>Today:
0.0KWh
Meter
b) Load consume
User can check the load consumption if the device is plugged in a smart plug.
﹦﹦ ﹦ ﹦
Load consume
﹦﹦ ﹦ ﹦
>Load 1 consume
Load 2 consume
k) Energy Reset
User can reset the energy record here. Press up or down button to select and
press “OK” to confirm.
﹦﹦ ﹦Energy Reset ﹦﹦ ﹦ ﹦
Reset
No
﹦﹦ ﹦ ﹦
Grid Protection
﹦﹦ ﹦ ﹦
>O/V Stage1
j) Grid Protection
Usually end user do not need to set the grid Protection. All default value have
been set before leaving factory according to safety rules.
If need to reset, any changes should according to the requirement of local grid.
c) Meter
This function is made user check meter energy possible. (Meter energy
will show if user use SolaX meter)
﹦﹦ ﹦ ﹦
Meter
﹦﹦ ﹦ ﹦
>Today Export:
00.0KWh
295.0

Solax X3 series Specifications

General

Type	Hybrid Inverter
Protection Rating	IP65
Output Frequency	50 Hz / 60 Hz
Communication Interfaces	WiFi, Ethernet, RS485
Output Voltage	230V
Operating Temperature	-25°C to 60°C
