2.1.2.3 PS2ROU part list
Unit
Description
PS2RDU
Remote Drive Unit
Amplify TX signals
Amplify RX signals
Remove other signals through BPF
RPSU (AC)
Remote AC Power Supply Unit
Input power: 100~240 VAC
Output power: +29.2 VDC
RPSU (DC)
Remote DC Power Supply Unit
Input power: -42 ~ -56 VDC
Output power: +29.2 VDC
R-OPTIC
Remote Optic
Convert RF signals into optical signals and vise versa; Compensate optical loss
Communicate with legacy BIU or iBIU/OEU though the FSK modem
5dBo optical link between ODU (OM4) and ROU
10dBo optical link between ODU (OM1) and ROU
Fiber Connector: SC/APC Connector
Fiber Type: Single Mode Fiber
Optical Wavelength: 1310/1550 WDM
RCPU
Remote Central Processor Unit
Controls signal of each unit
Monitors legacy BIU or iBIU/ODU/OEU through the FSK modem
CU-70P80P90I
Multiplexer 3-band
Combine TX signals from 3 RDUs; Distribute RX signals to 3 RDUs
Allow to use a single antenna port for 5 bands
ROU Enclosure
Enclosure to satisfy UL Type 4X
