2.1.3.2 PS2ROU Power Supply
AC Power Supply
The PS2ROU supports only AC 100~240V input power and only a single type of power cable is
provided. The pin discription of AC port is as below. Pay attention to the correct polarity.
Check if the connection is the same as one seen in the table above and make sure to turn the
power ON. The figure below is the AC power cable that comes with the unit.
Figure 4.5– AC Power Supply
