2.1.3.5 Multiplexer
Multiplexer it called combine unit(CU) works as a module to combine or distribute multiple signals
into one or two antennas.
This device has a port to combine multiple signals. You need to connect input and output ports of
RDU throughgh a corresponding port.
Figure 8. Multiplexer Outer Look
