3 . 1 . 1 TE M PE RA T UR E G AU GE :
T hi s gauge indi c a t e s t empera t ure o f engine c oolan t, G R EE N z one
indi c a t e s normal t empera t ure and R E D Z one indi c a t e s engine
o v erhea t ing . If t he needle move s be y ond normal range ,
t oward s R E D z one , f ollow t he pro c edure .
C H
1 . Dri v e s a f el y t o t he s ide o f road and st op y our t ra ct or .
2 . A llow t he engine t o run idle .
3 . If t he t empera t ure doe s no t go down , s hu t i t o ff and allow
s u ff i c ien t t ime f or i t t o c ool .
4 . V i s uall y in s pe ct t he f an bel t f or loo s ene ss, brea k age and all
wa t er ho s e c onne ct ion s f or lea k.
5 . If t he f an bel t i s OK and no c oolan t lea k i s no t i c ed c he ck t he
c oolan t le v el .
6 . A dd c oolan t i f required o t herwi s e c on t a ct y our neare st dealer .
Do no t remo v e t he radia t or c ap when t he engine and radia t or are ho t. B oiling ho t c oolan t and
st eam ma y blow ou t under pre ss ure , whi c h c ould c au s e s eriou s injur y. T he c ap should onl y be
t a k en o ff when t he c oolan t t empera t ure ha s lowered .
Ne c e ss ar y pre c au t ion t o be t a k en while opening t he radia t or c ap .
3 . 1 . 2 E N GI N E OIL P R ESS UR E I ND I CA TO R
T hi s indi c a t or indi c a t e s pre ss ure o f lubri c a t ing oil in t he engine . If t he
indi c a t or glow , st op t he engine and f ollow t he pro c edure :
1 . St op y our t ra ct or t o t he s ide o f road on le v eled s ur f a c e .
2 . W ai t f or s u ff i c ien t t ime a ft er st opping t he engine t o ge t down t he
oil f rom galler y t o oil s ump .
3 . P ull ou t t he dip st i ck, wipe o ff oil wi t h a c lean c lo t h .
4 . I n s er t t he dip st i ck, f ull y in t o t he oil le v el gauge guide , t hen pull
ou t t he gauge again . T he c orre ct oil le v el i s be t ween t he M AX.
& Min . mar ks on t he dip st i ck.
5 . If t he oil le v el i s low , remo v e t he oil f iller c ap and add oil o f t he
s pe c i f ied ty pe t o t he M AX. le v el .
6 . I n st all t he oil f iller c ap a ft er a t opup .
7 . Chec k t he oil pan and o t her par t s f or oil lea k age .
8 . St ar t t he engine , allow i t t o run idle and don 't ra c e i t immedia t el y
i f again t he red ligh t glow s, t hen c on t a ct y our neare st dealer .
Do not operate the engine if there is no oil pressure indication.
