SOLIS 20 User Manual

3 . 8 H Y DRAU LI C
3 . 8 . 1 H Y DRAU LI C SYSTE M
I n t hi s t ra ct or li v e h y drauli c syst em i s pro v ided . I n whi c h h y drauli c pump i s
dri v en b y engine and moun t ed a t c o v er o f engine . As t he engine run , t he
h y drauli c pump al s o st ar ts wor k ing . T ran s mi ss ion lubri c a t ion oil i s u s ed a s
h y drauli c oil .
3 . 8 . 2 T RAN SPO R T LO CK
It a cts a s s a f el y de v i c e during t ran s por t a t ion o f implemen ts. It i s lo c a t ed on f ron t
s ide o f H y drauli c Rear Co v er below dri v er s ea t.
Use : F or s a f e ty lo ck f ull y t igh t en t he re s pon s e v al v e b y ro t a t ing in c lo ck wi s e
dire ct ion
Response Valve should always be closed during implements transportation.
3 . 8 . 3 T HR EE POI N T LI NKA GE
T hree-poin t lin k age i s u s ed t o moun t t he implemen t, whi c h i s f ull y moun t ed ,
or s emi-moun t ed and u s ed f or di ff eren t f ield opera t ion . T hree-poin t lin k age
i s c on t rolled b y h y drauli c le v er . I n t hi s t wo lower lin k are a v ailable , o f whi c h
one s ide o f t he lower lin k i s a tt a c hed wi t h di ff eren t ial hou s ing and o t her i s
u s ed t o hi tc h t he lower pin o f t he implemen t. Li ft rod s are moun t ed on li ft arm
t ha t i s opera t ed t hrough ro cks ha ft. Loo s e s ide o f T op lin k i s u s ed f or
a tt a c hing upper hi tc h pin o f implemen t. T op lin k i s adju st able f or proper
s e tt ing o f implemen t and ea s e a t t he t iming o f joining .
3 . 8 . 3 . 1 LIFT R O D S (A & B)
If li ft rod i s f i tt ed wi t h li ft arm and lower lin k, t he leng t h o f li ft rod ( A&B ) c anno t
be adju st ed .
3 . 8 . 3 . 2 TOP LI NK (C)
F or leng t h adju st men t o f t op lin k, f i x t he t op lin k o t her end and t urn t he le v er
f or in c rea s ing or de c rea s ing t he leng t h . During f ield opera t ion lo ck t he t ube
t o a v oid unne c e ss ar y t urning .
3 . 8 . 3 . 3 LOWE R LI NK S (C)
Lower Lin ks are pro v ided f or hi tc hing t he implemen t.
3 . 8 . 3 . 4 A TT ACH I N G I M PLE M E N T TO 3 POI N T LI NKA GE
P o s i t ion t he t ra ct or t o align c orre s ponding lin k age wi t h t he hi tc h poin ts o f
implemen ts. K eep t he implemen t on hard & le v eled s ur f a c e and a tt a c h a s
per gi v en below in st ru ct ion s :
F ir st a tt a c h wi t h Le ft lower lin k ( E ) and Righ t Lower Lin k ( F )
T hen a t Las t a tt a c h wi t h T op Lin k (C)
3 . 8 . 3 . 5 D I R E C TIO NA L C O N T R OL V A LVE (DC V )
T he t ra ct or i s equipped wi t h s ingle a ct ing dire ct ional c on t rol v al v e . T he
opera t or i s wi t h a le v er lo c a t ed on LH S o f dri v er s ea t. A nd t he c oupler (qui ck
a tt a c h) i s a t rear s ide o f t ra ct or .
Use only single action cylinder implement.
