3.2.4 STARTING KEY SWITCH:
Functioning
of
starting
key
switch
is
as
below:
Ist Position (OFF) : All
the electrical systems
remain disconnected in
this position.
2nd Position (ON) : The
warning lights (Battery, Oil
Pressure indicator & other
Cluster Lights will be
functional in this position.
This is normal running
position after the engine is
started.
3rd
Position
(Use
of
Heater):
Turn the key slightly
clockwise and hold in
between ON & START
position for 3-5 Seconds so
that glow plugs can heat up
the air in the cylinders.
4th Position (START):
Immediate
after
the
use
of
air
heater
turn
th e
key
further
clockwise
to
Start
position
to
start
the
engine.
O
N H
EATE
R
START
NOTE : Do not keep the starter engaged more than 5-8 seconds. If engine stalls/fails to start then wait for 5-10 seconds
before re-engaging the starter, otherwise you may damage it.
Keep the switch in OFF condition when engine is also in OFF condition.
3.2.5 ENGINE STOP KNOB:
To stop the engine release the accelerator lever and pull the stopping
knob. After stopping the engine push it back to its original position.
3.2.6 FUSE BOX:
Fuse box is mounted under the right side of Fuel Tank. If an electrical
failure occurs, check for a blown fuse and replace with specified fuse
only.
CAUTION: Never install a wire instead for proper fuse.
3.2.7 Revolving Light Switch
Revolving light as show in the figure is used as the precession light
during working of the tractor in the field. ON/OFF switch is located on
dash board in control figure.
