3 . 1 . 3 R P M CUM H O UR R E C O RD E R
Green
Needle o f t hi s me t er indi c a t e s s peed o f engine in re v olu t ion per minu t e
and t he re c order me t er indi c a t e s t he number o f hour s c lo ck ed b y t he
engine .
G reen Z one s i s s a f e f or opera t ion .
Red
Yellow
3 . 1 . 4 F U EL G AU GE
F uel gauge gi v e s an appro x ima t e indi c a t ion o f t he quan t i ty o f f uel in
f uel t an k. If t he needle en t er s in R E D z one , re f ill t he f uel t an k.
E n s ure Min . 5 L t r . o f F uel in F uel T an k t o a v oid air lo ck ing
F uel T an k Capa c i ty 30 L t r .
Red
Green
3.1.5 BATTERY CHARGE INDICATOR
This indicator indicates that either battery is being charged or not.
Refer the below given observations with respect to different
CONDITIONS
Battery Charging
System Functioning
IGNITION SWITCH
ENGINE
INDICATOR
ON
OFF
GLOW
OK
ON
OFF
OFF
Charging System/Battery is defective,
Get both thing checked from electrician
ON
Start/Running
OFF
Battery being Charged
ON
Start/Running
GLOW
Charging System is defective/Battery
is draining out, get the charging system
checked from electrician.
3.1.6 HIGH BEAM INDICATOR
This blue light glows when Head Lights are in high beam mode.
3.1.7 LEFT SIDE INDICATOR
It glow when the left side indicator is switched ON
