To Next PageTo Next PageWhy is my SOLIS Solis-3P12K-4G not getting any power?
If your SOLIS Inverter is not powering on, there are several things to check: * Verify the PV input connections. * Ensure the DC input voltage is adequate (single phase >120V, three phase >350V). * Confirm that the PV+/- polarity is not reversed.
What to do if my SOLIS Inverter shows OV-G-V01/02/03/04 error?
If your SOLIS Inverter displays the error OV-G-V01/02/03/04, it could be due to a high resistance in the AC cable. Try replacing it with a larger size grid cable. Alternatively, if permitted by your electrical company, adjust the protection limit.
What to do if my SOLIS Solis-3P12K-4G Inverter displays UN-G-V01/02 error?
If your SOLIS Inverter displays the error UN-G-V01/02, use the user define function to adjust the protection limit if it’s allowed by electrical company.
How to fix SOLIS Solis-3P12K-4G Inverter when LCD shows initializing all the time?
If the LCD screen on your SOLIS Inverter is stuck on the initializing screen, check the following: 1. Make sure the connectors on the main board and power board are securely attached. 2. Verify that the DSP connector to the power board is also firmly connected.
General| Model | Solis-3P12K-4G |
|---|---|
| Rated Power | 12kW |
| Input Voltage Range | 200-1000V |
| Max. Input Voltage | 1100V |
| Number of MPPTs | 2 |
| Nominal AC Output Power | 12kW |
| AC Voltage Range | 310-480 V |
| Nominal Grid Frequency | 50/60 Hz |
| Total Harmonic Distortion (THD) | <3% |
| Euro Efficiency | 98.2% |
| DC Switch | Yes |
| Protection Degree | IP65 |
| Cooling Method | Natural convection |
| Max. DC Input Power | 18kW |
| MPPT Voltage Range | 200-850V |
| Max. AC Output Power | 13.2 kW |
| Nominal AC Voltage | 230/400 V |
| Power Factor | 0.8 leading to 0.8 lagging |
| Operating Temperature Range | -25°C to +60°C |
| Communication | RS485 |
| Humidity | 0-100% (non-condensing) |
| Warranty | 5 years standard |
