Page 6
The JEA controller consists of three main groups of features:
• The Front Display Panel with the user interface controls.
• The Rear Connector Panel for input, output and data cables.
• The Main Housing which includes the mounting clips, mounting screws and fascia.
3.1 FRONT DISPLAY
Note: First digit is used as minus sign when needed
Display also has decimal point which is lit when needed.
SOLLATEK INTELLIGENT CONTROLS
3. DESCRIPTION
Bluetooth status
On when transmitting
Flashing when connected to device
Compressor status
On when compressor on, otherwise o
Door Event
On when door is open, otherwise o
Alarm
On when fault occurs, otherwise o
Defrost Mode
On when controller is in defrost mode,
otherwise o
Eco Mode
On when controller in eco mode, otherwise
o
Back / cancel
Up button
Enter Menu List
Down Button
Enter /set
To Next Page
