Wall Mounting Installation
• To mount your rangehood on the wall, drill two 10mm
diameter holes 538mm apart aligning centred directly
over the cooktop and with the vent hole on the top of
the rangehood centred in the middle as well (as per the
diagram shown below).
• Insert two supplied plastic wall plugs into the holes.
• Insert two screws into the upper two plastic wall plugs
and tighten them leaving 3mm protruding from the wall.
• Mount the rangehood onto the two screws and mark the
bottom two screw positions.
40
0
• Carefully remove the rangehood and drill the bottom
two screw holes.
• Insert two supplied plastic wall plugs into the holes.
• Mount the rangehood on the top screws, insert the
bottom screws and fully tighten all the screws.
• WARNING: Failure to install the screws or fixing device
in accordance with these instructions may result in
electrical hazards.
• Sôlt recommends the wearing of proper protection
during installation.
400
80
155
40
69
Need Help? You can speak to our
Support Team by calling 1300 11 4357,
or simply reach out by emailing us at
support@residentiagroup.com.au
Installation Instructions (continued)
