8
INSTALLING THE HIGHLAND
When installing the Highland grow light, take note of the polarity groove on
the track rail. The side of the Highland with no writing on the box should face
the polarity groove of the track light rail. The side of the Highland with
writing and access door should be on the opposite side of the polarity groove.
1. Make sure the power is off.
2. Insert the Highland into the track light rail. The base of the Highland
should be flush with the track light rail.
3. Switch the contact arm from left to right. The contact arm should be
completely to the right; clicking into place.
4. Position the head of the Highland towards your plants.
5. Switch the power switch from OFF to ON.
6. Removal is the reverse procedure. With the power off, switch the
contact arm form right to left and gently remove the highland from
the track rail.
