8 7 6 5 4 3 2 1
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
1 2000-010
FRAME CDR-2000 MAIN
WELDMENT
BASE, RIGHT SIDE 1
2000-015 LOCATOR PLATE 1
3000-409 SCREW, 3/8-16X1 HEXHD SS 4
3010-203 PEM, FHS-207-8 4
3010-201 PEM, YC3-16144 2
3010-206 PEM, FHS 420-12 4
2000-024 SUPPORT CHANNEL 1
SIDE, LEFT 1
2000-014 FILLER, LEFT SIDE 1
3010-203 PEM, FHS-207-8 4
3010-201 PEM, YC3-16144 2
3010-212 PEM, FHS-440-6 4
3010-205 PEM, FHS-832-6 6
3010-204 PEM, FHS-0518-8 4
E
0500-015 LOCATOR HSG #10 2
PARTITION, LASERED 1
ANGLE, BACK LASERED 1
CHANNEL, TOP 1
CHANNEL, HINGE 1
CHANNEL, INTAKE 1
2000-035 BOARD, DISCHARGE 1
3000-303 NUT, FLANGE 1/4-20 2
3010-153 STUD, SCRAPER 2" 1
2000-431
SHAFT,ALIGNMENT, IDLER
SUPPORT
D
3000-102 WASHER, LOCK SPLIT 5/16 3
3000-406 SCREW, 5/16-18 X 3/4 HEXHD GR8 3
3000-401
SCREW, 6 X 3/8 HEX WSH SLOTTED
SELFTAP
4000-233 SPACER, HEX 0.5 X 1.0 4
2000-415 LEG, ASM COMPLETE 4
4000-200 INSERT, LEG ADJ 1
2000-413 LEG, WELDMENT TUBE&PLUG 1
2 2000-401 ROLL ASM LOWER 1
2000-407 SHAFT, UPPER AND LOWER 1
2000-457 ROLL SYNTHETIC/PIPE 20" 1
2000-403 PIPE ROLL 21.110 1
2000-451 ROLL ETF 00039TIVAR 20.125 1
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
BRACKET, DISK 2
3010-302 PIN, 21S 187-125 1
5 2000-120 COVER,SAFETY ASSY 1
COVER, SAFETY 1
HOPPER, SAFETY 1
2000-124 BAR, SAFETY 1/4 3
4000-150 MAGNET,SAFETY COVER 1
3010-500 RIVET, 1/8 X .375 1
2000-123 HINGE, SAFETY COVER 2
6 2000-301 PANEL, LOUVERED 1
7 2000-302 COVER, HOUSING 1
8 2000-231 ECCENTRIC PLATE 2000 1
9 3000-101 WASHER LOCK #10 INT TOOTH 18
10 3000-402 SCREW, 10-32 X 3/8 TRUSS PH SS 19
11 3000-201 WASHER, FLAT 3/8 2
12 3000-103 WASHER, LOCK SPLIT 3/8 2
13 3000-409 SCREW, 3/8-16X1 HEXHD SS 2
14 2000-500 SCRAPER COMPLETE #1 1
2000-520 SHAFT, SCRAPER #1 2000 1
2000-510 SCRAPER #1 1
3010-202 PEM, FHS-0420-16 8
3000-303 NUT, FLANGE 1/4-20 8
3010-150 STUD, SCRAPER 6 1/4" BENT 2
3000-306 NUT, HEX 1/4-20 2
4000-251 SPRING, SCRAPER 2
15 2000-501 SCRAPER,COMPLETE #2 1
2000-521 SHAFT, SCRAPER #2 2000 1
2000-511 SCRAPER #2 1
3010-202 PEM, FHS-0420-16 8
3000-303 NUT, FLANGE 1/4-20 8
3010-100 STUD,SCRAPER 21/32 BENT 2
4000-251 SPRING, SCRAPER 2
3000-306 NUT, HEX 1/4-20 2
16 2000-502 SCRAPER,COMPLETE #3 1
2000-512 SCRAPER #3 1
2000-522 SHAFT, SCRAPER #3 2000 1
3010-202 PEM, FHS-0420-16 8
3000-303 NUT, FLANGE 1/4-20 8
3010-151 STUD, SCRAPER 1 3/8" 2
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
23 2000-417 PLATE, ADJUST 2
24 2000-423 HANDLE, ROLL ADJUST 2
25 2000-230 PLATE, TAKEUP SUPPORT 1
26 4000-521 SPROCKET 41B11 W/ BUSHING 1
4000-501 SPROCKET 41B11H TAKEUP 1
4000-551 BUSHING 08DU14 GARLOCK 1
27 3000-408
SCREW, 3/8-16 X 3/4 CARRIAGE
BOLT
28 4000-400 KNOB, LOCKING 2
29 2000-627 SWITCH PLATE, GEN 2 1
2000-335 SWITCH PLATE 1
SWITCH POWER RED 1
SWITCH POWER GREEN 1
5000-226 E-STOP 1
5000-228 LABEL, E-STOP 2
30 5000-225 SWITCH, ELECTRONIC 2
31 3000-204 WASHER, FLAT #4 4
32 2000-632 RELAY 110 VAC 1
2000-328 BRACKET, RELAY 1
3010-205 PEM, FHS-832-6 3
3010-206 PEM, FHS 420-12 1
5000-230 HARNESS, POWER MOLDED 1
5000-150 RELAY, 120 VAC 1
3000-416 SCREW, 8-32 X 1 PAN HD PH 1
3000-300 NUT, FLANGE 8-32 3
33 4000-502 SPROCKET 41B16H X 3/4 W/ KEY 1
34 4000-361
CHAIN 41 RIV 86 INCL 1 C/L
(2000)
35 4000-301 BUMPER, 3M 2
36 5000-130
MOTOR/BASE ASSY BALDOR
3/4HP
5000-108 GEARMOTOR, BALDOR 3/4HP 1
3000-414 SCREW, 5/16-18 X 1 HEXHD 4
3000-305 NUT, FLANGE 5/16-18 4
2000-019 BASE, MOTOR W/ STUDS 1
2000-018 BASE,MOTOR 1
3010-215 PEM, FH 518-8 ZI 9
37 3000-305 NUT, FLANGE 5/16-18 9
38 5000-276 BUSHING, 90 STR REL HEYCO1320 1
39 5000-278 BUSHING, FINGER .625 HOLE 1
ITEM
NO.
PART NUMBER DESCRIPTION QTY.
63 5000-272
CABLE TIE, 3M
5
64 3000-104
WASHER, LOCK SPLIT #4
4
65 5000-261
ORANGE WIRE NUT
5
F
E
D
C
4000-100 BEARING, R12RS ROLL 2
2000-412 SPROCKET 41B18H ROLL 1
2000-317 DISC LOWER COMPLETE 1
2000-321 DISC, LOWER 1
2000-023 BRACKET, DISC 2
3010-302 PIN, 21S 187-125 3
3000-225 WASHER, NYLATRON 1.50 2
2000-411 ECCENTRIC, UNIVERSAL 2
3 2000-400 ROLL ASM UPPER 1
2000-407 SHAFT, UPPER AND LOWER 1
3000-306 NUT, HEX 1/4-20 2
4000-151 MAGNET,SCRAPER SHAFT 1
17 2000-503 SCRAPER, COMPLETE #4 1
2000-523 SHAFT SCRAPER #4 2000 1
2000-513 SCRAPER #4 1
3010-202 PEM, FHS-0420-16 8
3000-303 NUT, FLANGE 1/4-20 8
3010-152 STUD, SCRAPER 2 1/2" 2
3000-306 NUT, HEX 1/4-20 2
4000-251 SPRING, SCRAPER 2
40 3000-403
SCREW, 1/4-20 X 1/2 THUMB
C
W/SHOULDER
41 3000-303 NUT, FLANGE 1/4-20 8
42 3000-302 NUT, ACORN 1/4-20 4
43 3000-404 SCREW, 1/4-20 X 3/4 HEXHD 4
44 3000-309 NUT, HEX 4-40 4
45 5000-317 LABEL, NSF 1
46 5000-314 LABEL, "DO NOT OPERATE..." 1
47 5000-312 LABEL, "SOMERSET" 3" 1
48 5000-313 LABEL, "KEEP FINGERS..." 1
LABEL, CCW INDICATOR
2000-457 ROLL SYNTHETIC/PIPE 20" 1
18 2000-600 TRAY, INTAKE ASSY 1
49 5000-316
GRADUATED
1
2000-403 PIPE ROLL 21.110 1
B
2000-451 ROLL ETF 00039TIVAR 20.125 1
4000-100 BEARING, R12RS ROLL 2
2000-412 SPROCKET 41B18H ROLL 1
2000-318 DISC, TOP COMPLETE 1
2000-320 DISC, TOP 1
2000-300 TRAY, INTAKE 1
3010-206 PEM, FHS 420-12 7
2000-304 BOARD, INTAKE 1
2000-303 BOARD, INTAKE 1
3010-206 PEM, FHS 420-12 2
SCREW, 6 X 3/8 HEX WSH SLOTTED
50 5000-315
LABEL, CW INDICATOR
GRADUATED
B
51 5000-311 LABEL, ETL 1
52 2000-119 GUARD, OPTIONAL LWR RLR 1
53 3000-106 WASHER, LOCK SPLIT 1/4 2
54 3000-410 SCREW, 1/4-20 X 1/2 HEXHD 2
2000-023 BRACKET, DISC 2
3000-401
SELFTAP
6
55 3000-340 SCREW, 10-32 X 1/4 SET HEX 4
3000-225 WASHER, NYLATRON 1.50 2
3010-302 PIN, 21S 187-125 3
2000-411 ECCENTRIC, UNIVERSAL 2
4 2000-402 ROLL,ASM MIDDLE UHMW 20" 1
3000-306 NUT, HEX 1/4-20 2
19 3000-300 NUT, FLANGE 8-32 9
20 3000-102 WASHER, LOCK SPLIT 5/16 7
21 3000-405 SCREW, 5/16-18 X 1/2 HEXHD 7
56 4000-300 LEG TIP RUBBER 4
57 4000-011 SPACER .50ID X .78OD X .123 PL 1
58 3000-225 WASHER, NYLATRON 1.50 3
59 2000-630
SPROCKET 41B11H IDLER
W/BUSHING
2000-408 SHAFT, MIDDLE 20 1
A
2000-457 ROLL SYNTHETIC/PIPE 20" 1
22 2000-418 SPACER TUBING 4
2000-430 SPROCKET 41B11H IDLER 1
4000-550 BUSHING, GARLOCK 1
UNLES S OTHERWI SE SPECIFI ED:
SOMERSET INDUSTRIES, INC.
A
NORTH BILLERICA, MA 01862
2000-403 PIPE ROLL 21.110 1
2000-451 ROLL ETF 00039TIVAR 20.125 1
60 4000-252
SPRING, EXTENSION, 4LG X .5 DIA.
X .063
DIMENSIONS ARE IN INCHES [MILLIMETER]
.XX .015 [ .4]
.XXX . 005 [ .13] FRACTIONAL 1/32 [ .8]
.XXXX .0 005 [ .013] ANGULAR: 1
TITLE:
2000 EXPLODED
4000-100 BEARING, R12RS ROLL 2
61 2000-428 ARM, IDLER 1
PROPRIETARY AND CONFIDENTIAL
INTERPR ET DRAWING PER:
NAME
DATE
2000-412 SPROCKET 41B18H ROLL 1
2000-316 DISC MIDDLE COMPLETE 1
62 4000-303 LEG, BUMPER 1
THE INFORMATIO N CONTAINED IN THIS
DRAWING AND AS SOCIATED CAD DATA
FILES IS THE SOL E PROPERTY OF
SOMERSET INDU STRIES. IT MAY NOT
BE REPRODUCED IN PART, OR AS A
ANSI Y14.5M - 1982
MATERI AL
SEE NOTES
FINISH
DRAWN
CHECKED
ENG APPR.
G. HURLEY 12/18/2012
SIZE
D
DWG. NO.
2000-PART
REV
C
2000-319 DISC, MIDDLE 1
WHOLE, OR SEN T TO ANY OTHER VEND OR,
WITHOUT THE EX PRESS WRITTEN
CONSENT OF SO MERSET INDUSTRIES.
DATABASE:SOLIDWORKS
MFG APPR.
Q.A.
SCALE: 1:2.5
WEIGHT N/A
SHEET 2 OF 2
8 7 6
5
4 3 2 1
