TECHNICAL CHARACTERISTICS
FX24 / FX230
Electronic controller 24 V 230 V
Power supply 230 V AC ± 10% - 50 Hz 230 V CA ±10 % - 50 Hz
Mains/low voltage insulation
> 2 M W 500 V DC > 2 M W 500 V DC
Operating temperature -10 / +55 °C -10 / +55 °C
Motor output current level 3.5 A + 3.5 A max. 1.25 A + 1.25 A max.
Motor relay communication current 10 A 10 A
Max. motor power 40 W (24 V DC) 300 W (24 V DC)
Accessory power supply 24 V AC 24 V AC
Gate open indicator NO contact (24 V AC - 1 A max.) Contact NO (24 V AC - 1 A max.)
Blinking light 24 V AC - 25 W max. 40 W
Battery (ref. 9014611)
Charge voltage 27.2 V DC 27,2 V DC
Charge current 130 mA 130 mA
Battery capacity 2 x (12 V 1.2 Ah) 2 x (12 V 1.2 Ah)
Flat battery protection threshold 20.4 V DC 20,4 V DC
Battery recharge time 12 to 14 hours 12 to 14 hours
IXENGO S 24 V / 230 V
Power supply 24 V DC 230 V DC
Rotation speed 3800 rpm 2800 rpm
Power consumption 40 W 210 W
Current consumption 1.5 A 0.5 A
Push and pull torque 2000 N 2000 N
Useful travel 280 mm 280 mm
Drive rod speed 14 mm/s 12 mm/s
Obstacle detection (impact reaction) Built-in torque limiter Electronic clutch on the control panel
Limit stops Built-in magnetic and adjustable -
Manual operation By unlocking key By unlocking key
Nbr. of operations per 24 hours 60 operations 60 operations
Maximum gate section length 1800 mm 1800 mm
Maximum gate section weight 250 kg 250 kg
Ambient conditions -20°C to +60 °C -20 °C to +60 °C
Protection level IP44 IP44
Lubrication Greased for life Greased for life
Capacitor - 6.3 µF
IXENGO L 24 V
Power supply 24 V DC
Rotation speed 3800 rpm
Power consumption 40 W
Current consumption 1.5 A
Push and pull torque 2000 N
Useful travel 410 mm
Drive rod speed 14 mm/s
Obstacle detection (impact reaction) Built-in torque limiter
Limit stops Built-in electromechanical and adjustable
Manual operation By unlocking key
Nbr. of operations per 24 hours 60 operations
Maximum gate section length 4000 mm
Maximum gate section weight 400 kg
Ambient conditions -10°C to +60 °C
Protection level IP44
Lubrication Greased for life
