Connect the WT setting tool - Ref. 9013142.
Ensure that the exterior Venetian blind is at least 30 cm below the stop on the mushroom
position.
Press the
Ÿź
button on the WT setting tool for 15 seconds.
)7KHPRWRUEULHÀ\URWDWHVWZLFH
)The current position of the Venetian blind is stored as the lower position.
)The upper end limit position is stored at 120 turns above the lower end limit
position.
,I\RXGRQRWKDYHWKH:7VHWWLQJWRRO\RXFDQSHUIRUPWKLVRSHUDWLRQE\SUHVVLQJWKHŸ
DQGźEXWWRQVRQDQRQORFNLQJGRXEOHSXVKEXWWRQ
The motor does not operate. Check:
That the motor wiring is correct
That the motor has not undergone a thermal cutout
)If it has, wait for the motor to cool down
That the appropriate cable has been used
That the motor used is definitely a J4 WT motor (read the label)
7.5. Return to factory mode
7.6. Troubleshooting
