User Manual SPA Snow Pack Analyser
- 28 -
Important:
If strings are not transmitted, then the string indices shift. For example if only the
strings "Main results", "Peripheral results", and "Sensor 1: aux values" are output
(delivery status), then the index assignment would be as following:
i String label
00 Main results
01
Peripheral
results
02
Sensor 1:
aux. values
The units and decimal places of the values 1 – 4 and additional information are:
Value Unit Decimal
Place
Ice content % 1
Water content % 1
Snow density kg/m³ 0
SWE mm 0
Snow depth cm 1
Length corr. (Analog 1) mm 0
Chip temperature °C 1
Capacitance pF 0
Phase ° 1
Tab. 4: Units and decimal places; consider that at the SPA the values Snow depth and Length
corr. do not represent reasonable values
