SMA 210/410 Deployment Guide
Deploying SMA on the LAN
4
15
Deploying SMA on the LAN
The following procedures explain how to configure your gateway appliance on the LAN:
• Connecting the SMA to the Gateway
• Configuring SMA to LAN Connectivity
Connecting the SMA to the Gateway
To connect the SMA on the LAN:
1 Connect one end of an Ethernet cable to an unused port on your LAN hub or switch.
2 Connect the other end of the Ethernet cable to the X0 port on the front of your SonicWall SMA 210/410.
The X0 Port LED lights up indicating an active connection.
3 Configure the SMA X0 IP address. Refer to Configuring the X0 IP Address for more information.
Configuring SMA to LAN Connectivity
In order for users to access local resources through the SMA appliance, you must configure your gateway device
to allow an outside connection through the SMA into your LAN.
To allow an SMA to LAN connection:
1 Log into your gateway appliance as an administrator and navigate to the Network > Address Objects
page.
2 In the Address Objects tab, click Add.
3 In the Add Object dialog box, create an address object for the X0 interface IP address of your SMA:
4 Click Add to create the object. After adding, click Close.
5 Click Add again to create an address object for the NetExtender range.
NOTE: Before continuing, you must add a new SMA custom zone. Refer to Adding a New SMA Custom
Zone for more information.
Name Name for the SMA appliance
Zone Assignment SMA
Type Host
IP Address SMA appliance X0 IP address (default 192.168.200.1)
