Connecting the SMA on a New DMZ
8
5 On the Server Private Network Configuration page, enter the following server and SMA information, and
then click Next:
6 On the Server Public Information page, accept the default IP address, or enter an IP address in your
allowed public IP range. Click Next.
7 The Public Server Configuration Summary page displays all the configuration actions that will be
performed. Click Apply to create the configuration and allow access from the WAN to the SMA on the
DMZ.
Allowing an SMA to LAN Connection
When users have connected to the SMA, they need to be able to connect to resources on the LAN.
To allow an SMA to LAN connection:
1 Navigate to the Network > Address Objects page on the gateway appliance.
2 In the Address Objects tab, click Add.
3 In the Add Address Object dialog box, create an address object for the X0 interface IP address of your
SMA appliance:
4 Click Add to create the object. Once done, click Close.
5 Click Add again to create an address object for the NetExtender range.
Server Name Specify the name for the SMA appliance
Server Private IP Address SMA appliance X0 IP address
Server Comment Brief description of the server
NOTE: The default IP address is the WAN IP address of your SonicWall security appliance. If you
accept this default, all HTTP and HTTPS traffic to this IP address will be routed to your SMA
appliance.
Name Name of the SMA appliance
Zone Assignment SMA
Type Host
IP Address SMA appliance X0 IP address (default 192.168.200.1)
