SMA 210/410 Deployment Guide
Connecting the SMA on a New DMZ
9
6 In the Add Address Object dialog box, create an address object for the NetExtender range:
7 Click Add to create the object. Once added, click Close.
8 On the Network > Address Objects page, click the Address Groups tab.
9 Click Add Group.
10 In the Add Address Object Group dialog box, create a group for the X0 interface IP address of your SMA
appliance and the NetExtender IP range:
Enter a name for the group.
In the left column, select the address objects you created and click the right arrow button.
Click OK to create the group when both objects are in the right column.
11 Navigate to the Firewall > Access Rules page, and select the Matrix view style.
12 Click the SMA > LAN icon.
Name Name for NetExtender range
Zone Assignment SMA
Type Range
Starting IP Address Start of the NetExtender IP address range (default 192.168.200.100)
Ending IP Address End of the NetExtender IP address range (default 192.168.200.200)
