Sonim XP3340 SENTINEL User Manual

14
Getting Started
Getting Started
This section provides information on using your Sonim
XP3340 SENTINEL phone.
The list of items in the Sonim XP3340 SENTINEL phone
box are:
•  User Guide CD
•  Sonim 3 Year Warranty Flyer
•  Quick Start Guide
•  Registration Card
•  Welcome Letter
•  Screwdriver
•  Adaptor
•  USB Cable
•  Charger
•  Belt Clip
Battery Usage
•  Use only a Sonim XP3340 SENTINEL certied
battery that is designed for this phone model.
•  The use of other batteries may void the warranty
terms of your phone and cause damage.
•  It is recommended to protect the battery
from extreme temperature environments and
moisture.
•  Please keep the battery out of the reach of children.
Inserting the Battery
1 Unscrew Cover
To open the battery cover,
rotate both the battery cover
screws in an counter clockwise
direction (as shown in the
gure). Sometimes, the battery
cover may be tight and some
extra effort is required to open
it. You can use the screwdriver
provided to open the screws.
2 Lift Cover
Lift the back cover to reveal the
battery slot.
3 Insert Battery
Insert the battery and ush into
the battery slot such that the
three metallic contacts at the
top of the battery are aligned
with the metallic contacts within
the battery compartment.

Sonim XP3340 SENTINEL Specifications

Operating Environment

operational temperature range	-20˚C to +55˚C
vibration protection	5Hz to 500Hz
shock resistance	up to 4G

Display

display size	2 inch
display resolution	240x320
display brightness	280cd/m²

Battery

battery capacity	1750 mAh
talk time	20 to 24 hours
standby time	over 800 hours

Camera

camera resolution	2 MP
camera features	LED Flash
torch light	LED

Ports & Interfaces

headset port	3.5mm waterproof
USB data port	proprietary cable
Bluetooth version	2.1

Weight and Dimensions

size	126mm x 60mm x 25mm
weight	185 grams
impact resistance	2 meter drop onto concrete
