Sonim XP3340 SENTINEL User Manual

16
Getting Started
CAUTION: There is a risk of explosion while
charging if the battery has been replaced by an
incorrect type.
Set Battery Alert
When you set the battery alert, every time the battery
charge is low you hear an alarm. To set the battery alert
select Menu > Profiles > General > Customize > Extra
tone > Warning. Select to activate the alert.
Your SIM Card
Purchase a SIM card from your mobile operator. The
SIM card associates your network services (for example,
phone number, data services, and so on) with your
phone.
Inserting the SIM Card
1 Switch Off Phone
Ensure that the phone is switched off.
2 Lift Cover
Lift the battery cover and remove the battery. For
instructions refer “Inserting the Battery” on page 14.
3 Place SIM Card
Place the SIM card by
pushing it upward in the
designated slot located
under the battery.
4 Lock Cover
Reinsert the battery and the cover. Turn the battery
cover screws clockwise to lock the battery cover.
Removing the SIM Card
1 Switch Off Phone
Ensure the phone is switched off.
2 Lift Cover
Lift the battery cover and remove the battery. For
instructions refer “Inserting the Battery” on page 14.
3 Remove SIM Card
Remove the SIM card by pushing it downward from
the slot.
4 Lock Cover
Reinsert the battery and the cover.

Sonim XP3340 SENTINEL Specifications

Operating Environment

operational temperature range	-20˚C to +55˚C
vibration protection	5Hz to 500Hz
shock resistance	up to 4G

Display

display size	2 inch
display resolution	240x320
display brightness	280cd/m²

Battery

battery capacity	1750 mAh
talk time	20 to 24 hours
standby time	over 800 hours

Camera

camera resolution	2 MP
camera features	LED Flash
torch light	LED

Ports & Interfaces

headset port	3.5mm waterproof
USB data port	proprietary cable
Bluetooth version	2.1

Weight and Dimensions

size	126mm x 60mm x 25mm
weight	185 grams
impact resistance	2 meter drop onto concrete
