SONIX SN32F268 - Page 16

SN32F260 Series
32-Bit Cortex-M0 Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 16 Version 1.5
SN32F265J (QFN 33pins)
VREG33
VDD
VDDIO1
P1.0
P1.1/CT16B0_CAP0
P1.2/SEL0
P1.3/SCK0
P1.4/MISO0
32
31
30
29
28
27
26
25
D+/PSCLK
1
●
24
P1.5/MOSI0
D-/PSDATA
2
23
P3.8/RESET/CT16B1_PWM22
VSS
3
SN32F265J
22
P3.7/SWDIO
P0.0/CT16B1_PWM0/CLKOUT
4
21
P3.6/SWCLK
P0.1/CT16B1_PWM1
5
20
P3.5/CT16B1_PWM21
P0.2/CT16B1_PWM2
6
19
P3.4
P0.3/CT16B1_PWM3
7
18
P3.3/CT16B1_PWM19
P0.4/CT16B1_PWM4/SCL0
8
33
VSS
17
P3.2/CT16B1_PWM18
9
10
11
12
13
14
15
16
P0.5/CT16B1_PWM5/SDA0
P0.10/CT16B1_PWM10
P0.11/CT16B1_PWM11
P0.12/CT16B1_PWM12
P0.13/CT16B1_PWM13
P0.14/CT16B1_PWM14
P0.15/CT16B1_PWM15
P3.1/CT16B1_PWM17
 Note: The pins which are not pin-out shall be set correctly to decrease power consumption in low-
power modes. Strongly recommended to set these pins as input pull-up.
