SONIX SN32F268 - Page 20

SN32F260 Series
32-Bit Cortex-M0 Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 20 Version 1.5
P1.5/MOSI0
I/O
P1.5 — General purpose digital input/output pin.
I/O
MOSI0 — Master Out Slave In for SPI.
P2.0~P2.10
I/O
P2.0~P2.10 — General purpose digital input/output pin.
P3.0~P3.3/CT16B1_P
WM16~19
I/O
P3.0~P3.3 — General purpose digital input/output pin.
O
CT16B1_PWM16~19 — PWM output 16~19 for CT16B1.
P3.4
I/O
P3.4 — General purpose digital input/output pin.
P3.5/CT16B1_PWM2
1
I/O
P3.5 — General purpose digital input/output pin.
O
CT16B1_PWM21 — PWM output 21 for CT16B1.
P3.6/SWCLK
I/O
P3.6 — General purpose digital input/output pin.
I
SWCLK — Serial Wire Clock pin.
P3.7/SWDIO
I/O
P3.7 — General purpose digital input/output pin.
I/O
SWDIO — Serial Wire Data input/output pin.
P3.8/RESET/CT16B1
_PWM22
I/O
P3.8 — General purpose digital input/output pin.
I
RESET — External Reset input. Schmitt trigger structure, active “Low”, normally
stay “High”.
O
CT16B1_PWM22 — PWM output 22 for CT16B1.
