6 Acquiring Images
68 Basic User Manual
A higher line density is useful in obtaining a very high resolution, such as the thyroid or testicles. A lower line
density is useful when scanning fetal heart beat and adult cardiac applications.
To adjust the line density
●
Tap the left part of
Line Density
on the touch screen to decrease the value.
●
Tap the right part of
Line Density
on the touch screen to increase the value.
■ Persistence
Persistence is used to average consecutive frames to provide a smoother appearance with less noise. Use lower
persistence values for fast-moving organs or tissues and higher persistence values for a smoother appearance.
To adjust the persistence:
●
Tap the left part of
Persist
on the touch screen to decrease the value.
●
Tap the right part of
Persist
on the touch screen to increase the value.
■ Dynamic Range
Dynamic range increases the adjustable range of contrast by enhancing the intensities of parts in the grayscale. It
optimizes the ultrasound image texture.
To adjust the dynamic range:
●
Tap the left part of
DYN
on the touch screen to decrease the value.
●
Tap the right part of
DYN
on the touch screen to increase the value.
■ Grayscale Curve
Grayscale curve optimizes the brightness of each pixel in accordance with the corresponding echo. To adjust the
grayscale curve:
●
Tap the left part of
Gray Map
on the touch screen to decrease the value.
●
Tap the right part of
Gray Map
on the touch screen to increase the value.
■ Adaptive Image Fusion
Adaptive image fusion provides choices of optimization methods to improve image quality through boundary
enhancement, image smoothing and system optimization.
To adjust the adaptive image fusion:
●
Tap the left part of
AdaptFusion
on the touch screen to decrease the value.
●
Tap the right part of
AdaptFusion
on the touch screen to increase the value.
■ Sector Width/Angle
Sector width (for linear probes) or sector angle (for curved and phased array probes) is used to adjust the frame
rate. You can adjust the sector width or angle to get more information without moving the probe.
The region of interest of the object can be adjusted after you adjust the sector width or sector angle.
To adjust the sector width/angle:
Tap the left or right part of
Sec. Width
on the touch screen to change the sector width or angle.
■ Sector Position
Sector position is used to move or rotate the image.
To adjust the sector position:
Tap the left or right part of
Sector Pos
on the touch screen to move or rotate the image.
