Sontex Supercom 636 - Page 22

Manual Supercom 636 R+W rev. 010312 22
Rsp_2
Field
Frame bytes in hex (Note 1) Coding Comment
Start, Length
68,Le Le,68
Control
08
Respond with user data, RSP_UD
Address
xx
Control Information
72
Variable structure respond
Identification number
xx xx xx xx
A, 32 bits
Manufacturer ID
EE 4D
C, 16 bits "SON"
Version of meter
00
C, 8 bits
Device type
dt
D, 8 bits
Access number
xx
C, 8 bits
Status
st
Ds, 8 bits
Signature (not used)
00 00
C, 16 bits
Energy totalizer 1 stored at month - 1
C4 10,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 2
84 11,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 3
C4 11,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 4
84 12,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 5
C4 12,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 6
84 13,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 7
C4 13,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 8
84 14,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 9
C4 14,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 10
84 15,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 11
C4 15,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 12
84 16,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 13
C4 16,en en,xx xx xx xx
B, 32 bits
Energy totalizer 1 stored at month - 14
84 17,en en,xx xx xx xx
B, 32 bits
Power maximum stored at - 1
D5 82 03,2B,xx xx xx xx
H, 32 bits
Power maximum stored at - 2
95 83 03,2B,xx xx xx xx
H, 32 bits
Power maximum stored at - 3
D5 83 03,2B,xx xx xx xx
H, 32 bits
Power maximum stored at - 4
95 84 03,2B,xx xx xx xx
H, 32 bits
Power maximum stored at - 5
D5 84 03,2B,xx xx xx xx
H, 32 bits
Power maximum stored at - 6
95 85 03,2B,xx xx xx xx
H, 32 bits
Power maximum stored at - 7
D5 85 03,2B,xx xx xx xx
H, 32 bits
Power maximum date/time stored at - 1
C4 82 03,6D,xx xx xx xx
F, 32 bits
Power maximum date/time stored at - 2
84 83 03,6D,xx xx xx xx
F, 32 bits
Power maximum date/time stored at - 3
C4 83 03,6D,xx xx xx xx
F, 32 bits
Power maximum date/time stored at - 4
84 84 03,6D,xx xx xx xx
F, 32 bits
Power maximum date/time stored at - 5
C4 84 03,6D,xx xx xx xx
F, 32 bits
Power maximum date/time stored at - 6
84 85 03,6D,xx xx xx xx
F, 32 bits
Power maximum date/time stored at - 7
C4 85 03,6D,xx xx xx xx
F, 32 bits
More records in next telegram
mo
Start of manufacturer specific data
Check Sum
cs
Stop
16
Start
User data
End
