Sontex Supercom 636 - Page 23

Manual Supercom 636 R+W rev. 010312 23
Rsp_3
Field
Frame bytes in hex (Note 1) Coding Comment
Start, Length
68,Le Le,68
Control
08
Respond with user data, RSP_UD
Address
xx
Control Information
72
Variable structure respond
Identification number
xx xx xx xx
A, 32 bits
Manufacturer ID
EE 4D
C, 16 bits "SON"
Version of meter
00
C, 8 bits
Device type
dt
D, 8 bits
Access number
xx
C, 8 bits
Status
st
Ds, 8 bits
Signature (not used)
00 00
C, 16 bits
Fabrication Number MET
0C,78,xx xx xx xx
A, 32 bits
Fabrication Number MIO
8C C0 C0 40,78,xx xx xx xx
A, 32 bits
Current date & time
04,6D,xx xx xx xx
F, 32 bits
Power
05,2B,xx xx xx xx
H, 32 bits [W]
Flow
05,3E,xx xx xx xx
H, 32 bits [m3/h]
Days without energy
02,FF 05,xx xx
C, 16 bits [days]
Days without flow
02,FF 06,xx xx
C, 16 bits [days]
High temperature
05,5B,xx xx xx xx
H, 32 bits [°C]
Low temperature
05,5F,xx xx xx xx
H, 32 bits [°C]
Identification number 1
8C 40,79,xx xx xx xx
A, 32 bits
Complementary counter 1 totalizer
84 40,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 1
C4 40,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 2
84 41,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 3
C4 41,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 4
84 42,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 5
C4 42,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 6
84 43,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 7
C4 43,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 8
84 44,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 9
C4 44,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 10
84 45,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 11
C4 45,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 12
84 46,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 13
C4 46,co co,xx xx xx xx
B, 32 bits
Complementary counter 1 totalizer stored at month - 14
84 47,co co,xx xx xx xx
B, 32 bits
More records in next telegram
mo
Start of manufacturer specific data
Check Sum
cs
Stop
16
