Sony Alpha 7RV User Manual

Help Guide
Interchangeable Lens Digital Camera
ILCE-7RM5 α7RV
Viewing images on a TV using an HDMI cable
To view images stored on this product using a TV, an HDMI cable (sold separately) and a TV equipped with an HDMI
jack are required. For details, refer to the operating instructions supplied with the compatible TV.
Note
Do not connect this product and another device using the output terminals of both. Doing so may cause a malfunction.
Some devices may not work properly when connected to this product. For example, they may not output video or audio.
Use an HDMI cable with the HDMI logo or a genuine Sony cable.
Turn off both this product and the TV.
1
Connect the HDMI terminal of this product to the HDMI jack of the TV using an HDMI cable (sold
separately).
Use an HDMI cable that is compatible with the HDMI Type-A terminal of the product and the HDMI jack of the TV.
2
Turn on the TV and switch the input.
3
Turn on this product.
Images shot with the product appear on the TV screen.
4
Select an image using the right/left sides of the control wheel.
The monitor of this camera is not lit up on the playback screen.
If the playback screen is not displayed, press the
(Playback) button.
5
398398

Sony Alpha 7RV Specifications

General

Effective Megapixels	61.0 MP
ISO Sensitivity	100-32000 (expandable to 50-102400)
Body Material	Magnesium alloy
Image Processor	BIONZ XR
Dimensions	131.3 x 96.9 x 82.4 mm
Weather Sealing	Yes
Sensor Type	35.9 x 24.0 mm (Full-frame) Exmor R CMOS
Autofocus Points	693 phase-detection, 425 contrast-detection
Image Stabilization	5-axis in-body stabilization
Viewfinder	Electronic, 9.44 million dots
LCD Screen	3.2 inch, 2.1 million dots, tilting touchscreen
Video Resolution	4K at 60p
Connectivity	Wi-Fi, Bluetooth, USB Type-C, HDMI
Battery Life	Approx. 530 shots (CIPA)
Continuous Shooting Speed	10 fps
Storage Media	Dual slots
Weight	Approx. 723 g (with battery and memory card)
