Help Guide
Interchangeable Lens Digital Camera
ILCE-7RM5 α7RV
Charging the battery pack using a charger
Insert the battery pack into the battery charger.
Place the battery pack on the battery charger aligning the direction of
(triangle) mark.
Slide the battery pack to the end.
1
Connect the power cord (supplied) to the battery charger, and connect the battery charger to the wall outlet
(wall socket).
When charging starts, the CHARGE lamp (A) lights up in orange.
You can check the approximate charging status with the charging status indicator lamp (B) as shown in the
following table. (The orange color indicates the lighting of the lamp.)
When the CHARGE lamp and charging status indicator lamp light up and then immediately turn off, the battery
pack is fully charged.
2
Charging status CHARGE lamp/Charging status indicator lamp
Immediately after attaching the battery pack - 30%
30% - 60%
60% - 90%
90% - Fully charged
Full charging completed
