Sony BDP-S485 - Page 74

B21 VDIN27 I/O
NC / MB140 (NOAH_Y5)
E20 VDIN28 I/O
NC / MB140 (NOAH_Y6)
C20 VDIN29 I/O
NC / MB140 (NOAH_Y7)
D21 VDIN30 I/O
NC
C21 VDIN31 I/O
NC
E21 VDIN32 I/O
XIF_CS
D20 VDIN33 I/O
NC / MB140 (HDMI_XINT
)
F21 VDIN34 I/O
NC
G20 VDIN35 I/O
NC / MB140 (NOAH_HCLK)
C24 CEC I/O
NC
F9 GPIO0 I/O
NC / MB140 (NOAH_DE)
E9 GPIO1 I/O
Start Bit (IFCON)
G9 GPIO2 I/O
NC / MB140 (CSI_NOAH_XCS)
D9 GPIO3 I/O
NC / MB140 (CSI_CKO)
A
D6 GPIO4 I/O
NC
A
E6 GPIO5 I/O
NC
A
E5 GPIO6 I/O
UPG_STATUS (IFCON)
A
C7 GPIO7 I/O
USB_VBUS_PCONT, USB Power Control
C25 HDMISCK I/O
HDMI I2C Clock
D24 HDMISD I/O
HDMI I2C Data
D25 HTPLG I/O
HDMI Hot Plug / MB140 (NC)
O/I RI52K
NC
L26 LCDRD I/O
IF_SDI
D3 RSTI I
Front-End Power on reset
K24 OPWRSB I/O
Power Control
K23 RESET
_
I
Power on reset
J25 UARXD I/O
RS232 Rx Pin
K26 UATXD I/O
RS232 Tx Pin
M24 VCLK I/O
IF_CLK
M23 VDATA I/O
IF_SDO
L25 VSTB I/O
XVMUTE, Video Mute
BDP-S485
6-8E
