Step 1: Installing the System
Install the system by referring to the illustration below.
• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed,
oiled, polished, etc.) floor, as staining or discoloration may result.
• Do not lean or hang on a speaker, as it may fall down.
• To assemble the speakers, refer to the supplied “Speaker Installation Guide.” (BDV-E980W only)
• You can install the speakers on a wall. For details, refer to the supplied “Speaker Installation Guide.”
Getting Started
How to position the system
AB
DE
C
G
H
F
A Front speaker (L (left))
B Front speaker (R (right))
C Center speaker
D Surround speaker (L (left))
E Surround speaker (R (right))
F Subwoofer
G Unit
H Surround amplifier
