BKM-220D SDI 4:2:2 Input Adaptor
BKM-220D SDI 4:2:2 Input Adaptor
Specifications
General
Voltage +5 V (supplied from the main
unit)
Power consumption
Approx. 1.5 W
Operating conditions
Temperature
0
°C to 35°C (32°F to 95°F)
Optimum temperature
20
°C to 30°C (68°F to 86°F)
Humidity 0% to 90% (no condensation)
Pressure 700hPa to 1060 hPa
Storage and transport conditions
Temperature –10°C to 40°C (14°F to 104°F)
Humidity 0% to 90%
Pressure 700 hPa to 1060 hPa
Maximum external dimensions (w/h/d)
100 × 20 × 162 mm
(4 ×
13
/16 × 6
1
/2 inches)
Mass Approx. 250 g (9 oz)
Input/output connectors
Digital input BNC × 2, with monitor output
connector
Signal characteristics
Digital component signals
Sampling frequency
Y/R-Y/B-Y: 13.5 MHz
Quantization
10bits/sample
MONITOR OUT
Output signal amplitude:
800 mVp-p ± 10%
Output impedance:
75-ohms unbalanced
Transmission distance
200 m (approx. 656 ft) max.
(When using 5C-2V coaxial
cables (Fujikura. Inc.) or
equivalent.)
Supplied accessories
Operating Instructions (1)
Design and specifications are subject to change
without notice
Available signal system
System Total number of
scanning lines
Number of available
scanning lines
Frame frequency Signal
standard
480/60I 525 483 30 SMPTE-259M
575/50I 625 575 25 ITU-R BT.656
