32
BKM-16R
INPUT/OUTPUT
LAN 10BASE-T/100BASE-TX connector: RJ-45 (x1)
DC 5 V / 12 V IN Circle 4-pin (male) (x1)
GENERAL
Power requirements DC IN: 5 V, 1.1 A (supplied by the connected monitor)
DC IN: 12 V, 0.5 A (supplied by the connected AC adaptor)
AC adaptor: AC IN: 100 V to 240 V, 50/60 Hz, DC OUT: 12 V, 3 A
Current consumption 5 V DC, 1.1 A / 12 V DC, 0.5 A
Power consumption Approx. 6 W
Operating temperature 32°F to 95°F (0°C to 35°C), Recommended: 68°F to 86°F (20°C to 30°C)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans. temperature 14°F to 104°F (-10°C to +40°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 16 3/4 x 2 3/8 x 7 inches (424 x 58.8 x 174.9 mm)
Weight 4 lb 10 oz (2.1 kg)
Supplied accessories AC adaptor (1), AC power cord (parts number: 1-757-562-1x1 for USA and Canada, 1-575-131-8x for Europe) (1), Rack mount brackets (2),
Rack mount attachment screws (4), Function labels (2), Operation manual (1)
BKM-227W
INPUT/OUTPUT
Composite input BNC (x1),
1 Vp-p ±3 dB sync negative
Y/C input Mini DIN 4-pin (x1)
Y: 1 Vp-p ±3 dB sync negative
C: 0.286 Vp-p ±3 dB (NTSC burst signal level),
0.3 Vp-p ±3 dB (PAL, PAL-M burst signal level)
Monitor out BNC (x1),
Loop-through, with 75 ohms automatic termination
Mini DIN 4-pin (x1),
Loop-through, with 75 ohms automatic termination
GENERAL
Voltage +3.3 V, +5 V (supplied from the main unit)
Power consumption Approx. 1.8 W
Operating temperature 32°F to 95°F (0°C to 35°C)
Recommended: 68°F to 86°F (20°C to 30°C)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans.
temperature
-4°F to +140°F (-20°C to +60°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 4 x 13/16 x 6 1/2 inches (100 x 20 x 162 mm)
Weight 8 oz (240 g)
Supplied accessories Operating Instructions (1)
BKM-220D
INPUT/OUTPUT
Serial digital interface BNC (x2),
Digital component signals sampling frequency:
Y/R-Y/B-Y: 13.5 MHz
Quantization: 10 bits/sample
Monitor out BNC (x1),
Output signal amplitude: 800 mVp-p ±10%
Output impedance: 75 ohms unbalanced
Transmission distance 200 m (approx. 656 ft) max.
(when using 5C-2V coaxial cables (Fujikura) or equivalent)
GENERAL
Voltage +5 V (supplied from the main unit)
Power consumption Approx. 1.5 W
Operating temperature 32°F to 95°F (0°C to 35°C)
Recommended: 68°F to 86°F (20°C to 30°C)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans.
temperature
-4°F to +140°F (-20°C to +60°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 4 x 13/16 x 6 1/2 inches (100 x 20 x 162 mm)
Weight 9 oz (250 g)
Supplied accessories Operating Instructions (1)
VMM 4SNY-3GB
Analysis Functions
Waveform monitor Includes cursors, vertical and horizontal sweeps, line select, bowtie, and lowpass lters
Vectorscope 75% and 100% display, Line select, gain, zoom, and cursors
Gamut display As composite or RGB grids, line select, upper and lower alarms
Picture display With line select
Audio display 16 channel display as bar, lissajous, , 5.1 or 7.1 displays, phase, and selection of levels
Alarms Alarm log
Inputs
Serial digital interface BNC (x2) terminating 75Ω
SD-SDI: Y/R-Y/B-Y: 13.5MHz/6.75MHz/6.75MHz
HD-SDI: Y/Cb/Cr: 74.25MHz/37.125MHz/37.125MHz
3G-SDI: Y/Cb/Cr: 148.5MHz/74.25MHz/74.25MHz
G/B/R: 148.5MHz/148.5MHz/148.5MHz
AES/EBU BNC (x1) terminating 75Ω
32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
Reference BNC (x1) terminating 75Ω
Analog Black Burst as NTSC or PAL
GENERAL
Voltage +3.3V, +5V (supplied from main unit)
Power consumption Approx. 12W
Operating temperature 0° to +35°C
Operating humidity 30% to 80% non-condensing
Operation pressure 700 hPa to 1060 hPa
Storage and trans temperature -20° to +60°C
Storage and trans humidity 5% to 90% non-condensing
Dimensions (W x H x D) 7.9 x 0.77 x 6.3 in (200.1 x 19.6 x 160.8mm)
Weight 1.30 lbs. (0.59kg)
Supplied Accessories CD with operating instructions
