Sony BVM-E250 - Page 31

31
Optional Accessories
BKM-250TG
INPUT/OUTPUT
Serial digital interface BNC (x2),
Digital component signals sampling frequency:
3G-SDI: Y/C
B/CR: 148.5 MHz/74.25 MHz/74.25 MHz,
G/B/R: 148.5 MHz/148.5 MHz/148.5 MHz
HD-SDI: Y/C
B/CR: 74.25 MHz/37.125 MHz/37.125 MHz,
SD-SDI: Y/C
B/CR: 13.5 MHz/6.75 MHz/6.75 MHz
Monitor out BNC (x2),
Output signal amplitude: 800 mVp-p ±10%
Output impedance: 75 ohms unbalanced
Transmission distance 3G-SDI: 70 m (approx. 230 ft) max.
(When using 5C-FB coaxial cables (Fujikura) or equivalent.)
HD-SDI: 100 m (approx. 328 ft) max.
(When using 5C-FB coaxial cables (Fujikura) or equivalent.)
SD-SDI: 200 m (approx. 656 ft) max.
(When using 5C-2V coaxial cables (Fujikura) or equivalent.)
GENERAL
Voltage +3.3 V, +5 V (supplied from the main unit)
Power consumption Approx. 4 W
Operating temperature 32°F to 95°F (0°C to 35°C)
Recommended: 68°F to 86°F (20°C to 30°C)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans.
temperature
-4°F to +140°F (-20°C to +60°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 4 x 13/16 x 6 1/2 inches (100 x 20 x 162 mm)
Weight 270 g (270 g)
Supplied accessories Operating Instructions (1)
BKM-244CC
INPUT/OUTPUT
Serial digital interface BNC (x2),
Digital component signals sampling frequency:
SD-SDI: Y/R-Y/B-Y: 13.5 MHz,
HD-SDI: Y/C
B/CR: 74.25 MHz
Quantization: 10 bits/sample
Monitor out BNC (x1),
Output signal amplitude: 800 mVp-p ±10%
Output impedance: 75 ohms unbalanced
Transmission distance SD-SDI: 200 m (approx. 656 ft) max.
(when using 5C-2V coaxial cables (Fujikura) or equivalent)
HD-SDI: 100 m (approx. 328 ft) max.
(when using 5C-FB coaxial cables (Fujikura) or equivalent)
GENERAL
Voltage +3.3 V, +5 V (supplied from the main unit)
Power consumption Approx. 4 W
Operating temperature 32°F to 95°F (0°C to 35°C)
Recommended: 68°F to 86°F (20°C to 30°C)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans.
temperature
14°F to 104°F (-10°C to +40°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 4 x 13/16 x 6 1/2 inches (100 x 20 x 162 mm)
Weight 9 oz (250 g)
Supplied accessories Operating Instructions (1)
BKM-243HS
INPUT/OUTPUT
Serial digital interface BNC (x2),
Digital component signals sampling frequency:
SD-SDI: Y/R-Y/B-Y: 13.5 MHz,
HD-SDI: Y/C
B/CR: 74.25 MHz
Quantization: 10 bits/sample
Monitor out BNC (x1),
Output signal amplitude: 800 mVp-p ±10%
Output impedance: 75 ohms unbalanced
Transmission distance SD-SDI: 200 m (approx. 656 ft) max.
(when using 5C-2V coaxial cables (Fujikura) or equivalent)
HD-SDI: 100 m (approx. 328 ft) max.
(when using 5C-FB coaxial cables (Fujikura) or equivalent)
GENERAL
Voltage +3.3 V, +5 V (supplied from the main unit)
Power consumption Approx. 2 W
Operating temperature 32°F to 95°F (0°C to 35°C)
Recommended: 68°F to 86°F (20°C to 30°C)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans.
temperature
-4°F to +140°F (-20°C to +40°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 4 x 13/16 x 6 1/2 inches (100 x 20 x 162 mm)
Weight Approx. 9 oz (250 g)
Supplied accessories Operating Instructions (1)
BKM-229X
INPUT/OUTPUT
RGB / Component
BNC (x3)
RGB: 0.7 Vp-p ±3 dB (Sync on Green, 0.3 Vp-p sync negative)
Component: 0.7 Vp-p ±3 dB
External sync input BNC (x1),
0.3 Vp-p to 4 Vp-p ± bipolarity ternary or negative polarity
binary
Mini DIN 4-pin (x1),
Loop-through, with 75 ohms automatic termination
GENERAL
Voltage +3.3 V, +5 V (supplied from the main unit)
Power consumption Approx. 4 W
Operating temperature 0°C to 35°C (32°F to 95°F)
Recommended: 20°C to 30°C (68°F to 86°F)
Operating humidity 0% to 90% (no condensation)
Operating pressure 700 hPa to 1060 hPa
Storage and trans.
temperature
-4°F to +140°F (-20°C to +60°C)
Storage and trans. humidity 0% to 90%
Storage and trans. pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 4 x 13/16 x 6 1/2 inches (100 x 20 x 162 mm)
Weight 9 oz (250 g)
Supplied accessories Operating Instructions (1)
