"DME-450P control"
If the Bvs-3000
operating indenpendently
rol of a DME-450P), the LED display is
602 when set to 6x2.
Control (remote control) of the DME-
450P is possible by setting the "EDITOR
ENABLE" switch on the BVS-3000 Series
switcher to "ON" and then setting the
DME pattern number. The LED display
will then read 612.
Series switcher is
(not in cont-
"asynchronous input video"
If the
using the PGM-BUS switch of the BVS-
3000
with
genlocked),
input video signal selected
switcher is synchronous
respect that switcher
the LED display
when set to 6x3.
If the input video signal selected with
the PGM-BUS switch is either misSing or
asynchronous, the LED display will read
613 and the PGM-BUS switch will begin
to flicker. If a synchronous input
video the switch
will stop flickering and the LED dis-
play will again return to 603.
Series
(signal
reads 603
signal is selected,
3-4
(9)
"control panel communication"
If the status of the communication line
the the
processor of the BVS-3000 Series switch-
the LED display reads 604
when set to 6x4.
between control panel and
er is normal,
If communication on this line is not
the LED display will read 614
and a buzzer will sound continuously.
If this the BVS-3000
switcher's power off once and
possible,
occurs, turn
Series
then back on again.
"check"
"lamp check"
The lamps of the switches on the cont-
rol panel of the BVS-3000 Series switch-
er will be lit one by one and checked
when the LED display is set to 900 and
then the "CUT" switch is pressed.
The status of the control panel will
return to normal after the last lamp
test ("DSK MIX") has been completed.
Press the "CUT"
halt the lamp test in the middle.
switch a second time to
"xPT-flicker"
In this mode, the crosspoint is auto-
Matically adjusted when the phase of
the input video signal is aligned with
that of the BVS-3000 Series switcher.
See the "Operation Manual" for proper
procedure.
BVS-3100P (EK)
