Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-7066-774-A VF-99 BOARD, COMPLETE
********************
(TR315E/TR415E/TR425E/TR515E/TR713E/TRV16E/TRV26E/TRV27E/
TRV27EP/TRV36E/TRV46E)
(Ref. No. 10,000 Series)
< CAPACITOR >
C901 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C902 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C903 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C904 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C905 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C906 1-162-638-11 CERAMIC CHIP 1uF 16V
C907 1-104-563-11 FILM CHIP 0.1uF 5% 16V
C908 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C909 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
! C910 1-163-017-91 CERAMIC CHIP 0.0047uF 5% 50V
(TYPE 3)
! C910 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
(TYPE 2)
! C911 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C912 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C913 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C914 1-113-984-11 TANTAL. CHIP 1.5uF 20% 35V
C915 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C916 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
< CONNECTOR >
CN901 1-573-506-41 CONNECTOR, FPC (NON ZIF) 4P
* CN902 1-580-057-11 PIN, CONNECTOR 4P
< DIODE >
D901 8-719-951-21 DIODE PR1102W-TR
D903 8-719-404-50 DIODE MA111-TX
D905 8-719-073-03 DIODE MA8082-TX
< IC >
IC901 8-759-196-14 IC BA7149F-E2
< COIL >
L901 1-412-031-11 INDUCTOR CHIP 47uH
L902 1-410-387-11 INDUCTOR CHIP 33uH
! L903 1-411-759-11 COIL, FERRITE (HLC)(K)(TYPE 2)
! L903 1-411-697-11 COIL, FERRITE (HLC)(TYPE 3)
< TRANSISTOR >
Q901 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q902 8-729-106-68 TRANSISTOR 2SD1615-T1GLGK
Q903 8-729-216-31 TRANSISTOR 2SA1163G-TE85L
Q904 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R901 1-216-817-11 METAL CHIP 470 5% 1/16W
R902 1-216-817-11 METAL CHIP 470 5% 1/16W
R903 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/16W
R905 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R906 1-216-813-11 METAL CHIP 220 5% 1/16W
(TYPE 3)
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(TYPE 2)
R907 1-216-845-11 METAL CHIP 100K 5% 1/16W
R908 1-216-852-11 METAL CHIP 390K 5% 1/16W
R909 1-216-833-11 METAL CHIP 10K 5% 1/16W
R910 1-216-835-11 METAL CHIP 15K 5% 1/16W
R911 1-216-160-00 RES,CHIP 27 5% 1/8W
R912 1-216-857-11 METAL CHIP 1M 5% 1/16W
R916 1-218-881-11 RES,CHIP 27K 0.50% 1/16W
R917 1-218-893-11 RES,CHIP 82K 0.50% 1/16W
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R919 1-216-843-11 METAL CHIP 68K 5% 1/16W
R920 1-216-837-11 METAL CHIP 22K 5% 1/16W
R921 1-216-795-11 RES,CHIP 6.8 5% 1/16W
(TYPE 3)
R921 1-216-800-11 RES,CHIP 18 5% 1/16W
(TYPE 2)
R922 1-216-847-11 METAL CHIP 150K 5% 1/16W
R923 1-216-857-11 METAL CHIP 1M 5% 1/16W
R924 1-216-862-11 RES,CHIP 2.7M 5% 1/16W
R925 1-216-862-11 RES,CHIP 2.7M 5% 1/16W
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R929 1-216-818-11 METAL CHIP 560 5% 1/16W
R930 1-216-791-11 METAL CHIP 3.3 5% 1/16W
R931 1-217-671-11 METAL CHIP 1 5% 1/10W
R932 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VARIABLE RESISTOR >
RV903 1-238-852-11 RES, ADJ, CERMET 470
RV904 1-238-862-11 RES, ADJ, CERMET 1M
< TRANSFORMER >
! T901 1-453-124-11 TRANSFORMER ASSY, FLYBACK (TYPE 3)
! T902 1-431-915-11 TRANSFORMER ASSY, FLYBACK (M) (TYPE 2)
< FLEXIBLE BOARD >
! W901 1-540-019-42 SOCKET ASSY, CRT
A-7073-437-A VF-119 BOARD, COMPLETE (TR516E)
**********************
(Ref. No. 10,000 Series)
< CAPACITOR >
C5401 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C5402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5403 1-135-179-21 TANTAL. CHIP 2.2uF 20% 16V
C5404 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5405 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5406 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5407 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C5408 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C5409 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C5410 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5411 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C5413 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C5414 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5415 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C5416 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
