6-35
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VF-120 VL-21/22
R5313 1-216-842-11 METAL CHIP 56K 5% 1/16W
R5314 1-216-850-11 METAL CHIP 270K 5% 1/16W
R5315 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5316 1-216-851-11 METAL CHIP 330K 5% 1/16W
R5317 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5318 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R5321 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5322 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5324 1-216-864-11 METAL CHIP 0 5% 1/16W
A-7073-787-A VL-21 BOARD, COMPLETE
*********************
(TR515E/TR516E/TR713E)
(Ref. No. 2,000 Series)
A-7073-808-A VL-22 BOARD, COMPLETE (TRV36E/TRV46E)
*********************
(Ref. No. 3,000 Series)
< CAPACITOR >
C151 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
C153 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
< CONNECTOR >
CN151 1-764-703-11 CONNECTOR, FFC/FPC (LIF) 4P
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
< COIL >
L151 1-416-344-11 INDUCTOR 10uH
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
< TRANSISTOR >
Q151 8-729-043-94 TRANSISTOR CPH3106-PM-TL
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
Q152 8-729-028-26 TRANSISTOR 2SK1829(TE85L)
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
< RESISTOR >
R151 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
R152 1-216-813-11 METAL CHIP 220 5% 1/16W
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
R153 1-216-821-11 METAL CHIP 1K 5% 1/16W
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
R154 1-216-845-11 METAL CHIP 100K 5% 1/16W
(TR515E/TR516E/TR713E/TRV36E/TRV46E)
MISCELLANEOUS
*************
67 1-475-619-11 SWITCH BLOCK, CONTROL (SS-8500)
73 1-418-215-21 SWITCH BLOCK, CONTROL (FK-8500)
(TR415E/TR425E/TR515E/TRV26E/TRV27E/TRV27EP/TRV36E)
73 1-418-215-61 SWITCH BLOCK, CONTROL (FK-8500)
(TR713E/TRV46E:AEP,UK,EE,NE,RU)
73 1-475-617-11 SWITCH BLOCK, CONTROL (FK-8500)
(TR315E/TR516E/TRV16E)
73 1-475-617-21 SWITCH BLOCK, CONTROL (FK-8500)
(TRV46E:E,HK,AUS,CN,JE)
151 1-475-620-11 SWITCH BLOCK, CONTROL (MF-8500)
157 1-790-334-11 CABLE, FLEXIBLE FLAT (FFC-257F)
209 1-668-957-11 FP-621 FLEXIBLE BOARD
210 1-672-454-11 FP-58 FLEXIBLE BOARD (for Video light models)
211 1-672-453-11 FP-56 FLEXIBLE BOARD
212 1-668-956-11 FP-620 FLEXIBLE BOARD (TR713E & TRV series)
254 1-672-455-11 FP-57 FLEXIBLE BOARD
(for Color view finder models)
308 1-783-241-11 CABLE, FLEXIBLE FLAT (FFC-235)
(for B/W view finder models)
358 1-668-963-21 FP-642 FLEXIBLE BOARD (for TRV series)
359 1-959-271-11 HARNESS (PD-108) (for TRV series)
401 8-848-722-01 DEVICE, LENS LSV-600A (SOC)
409 1-758-133-21 FILTER BLOCK, OPTICAL
412 1-668-959-11 FP-623 FLEXIBLE BOARD
760 1-658-213-11 FP-355 FLEXIBLE BOARD
762 1-657-786-13 FP-221 FLEXIBLE BOARD
764 1-658-214-11 FP-356 FLEXIBLE BOARD
803 1-657-785-11 FP-248 FLEXIBLE BOARD (DEW SENSOR)
817 1-657-784-11 FP-220 FLEXIBLE BOARD
D001 8-719-988-42 DIODE GL453
IC401 A-7030-961-A CCD BLOCK ASSY (207 SERVICE)
(Except TR713E/TRV46E)
IC401 A-7030-962-A CCD BLOCK ASSY (243 SERVICE)
(TR713E/TRV46E)
J001 1-565-276-31 JACK, ULTRA SMALL 1P (LANC)
J901 1-694-384-11 TERMINAL BOARD, BATTERY
LCD901 1-803-355-21 MODULE, CRYSTAL INDICATION
LCD902 8-753-023-37 LCX024AK-4/5 COMPLE
(for Color view finder models)
LCD903 A-7093-473-A INDICATION LCD BLOCK ASSY
M901 A-7048-875-A DRUM ASSY (DGH-0E2A-R)
M902 8-835-531-32 CAPSTAN ASSY
M903 X-3945-401-1 MOTOR ASSY, DC (LOADING)
M905 1-763-047-11 MOTOR, FOCUS STEPPING
M906 1-763-046-11 MOTOR, ZOOM STEPPING
MIC901 1-542-312-11 MICROPHONE
! ND801 1-517-752-11 TUBE, FLUORESCENT, COLD CATHODE
(for TRV series)
! ND5351 1-517-325-21 LAMP, FLUORESCENT (0.55 INCH)
(for Color view finder models)
S001 1-692-614-11 SWITCH, PUSH (3 KEY)
(Hi8 MP, ME/MP, REC PROOF)
S002 1-572-688-11 SWITCH, PUSH (1 KEY)(C.C. LOCK)
S003 1-572-688-11 SWITCH, PUSH (1 KEY) (EJECT)
S901 1-762-436-15 SWITCH, ROTARY (ENCODER)
SE451 1-803-041-11 SENSOR, ANGULAR VELOCITY (YAW)
(TR713E/TRV46E)
SE452 1-803-041-21 SENSOR, ANGULAR VELOCITY (PITCH)
(TR713E/TRV46E)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
