Sony CDP-M7 - Display Board Parts List

— 40 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
DISPLAY
BD
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R118 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R119 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R120 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R121 1-216-114-00 METAL GLAZE 510K 5% 1/10W
R122 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R127 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K
RV103 1-241-396-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* A-4673-994-A DISPLAY BOARD, COMPLETE (SP,HK,JE)
***********************************
* A-4673-998-A DISPLAY BOARD, COMPLETE (US,CND)
*********************************
* 4-955-901-01 CUSHION (FL)
* 4-977-695-01 HOLDER (FL)
< CAPACITOR >
C501 1-164-159-11 CERAMIC 0.1uF 50V
C502 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C503 1-162-292-31 CERAMIC 680PF 10% 50V
C504 1-162-294-31 CERAMIC 0.001uF 10% 50V
C505 1-162-294-31 CERAMIC 0.001uF 10% 50V
C506 1-164-159-11 CERAMIC 0.1uF 50V
C507 1-164-159-11 CERAMIC 0.1uF 50V
C508 1-164-159-11 CERAMIC 0.1uF 50V
C509 1-164-159-11 CERAMIC 0.1uF 50V
C511 1-126-177-11 ELECT 100uF 20% 10V
< CONNECTOR >
* CN501 1-568-845-11 SOCKET, CONNECTOR 31P
* CN502 1-568-832-11 SOCKET, CONNECTOR 13P
< FILTER >
FL501 1-517-462-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-759-377-67 IC uPD780205GF-016-3BA
< TRANSISTOR >
Q502 8-729-900-80 TRANSISTOR DTC114ES
Q503 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R502 1-249-413-11 CARBON 470 5% 1/4W F
R503 1-249-415-11 CARBON 680 5% 1/4W F
R504 1-249-417-11 CARBON 1K 5% 1/4W F
R505 1-247-807-31 CARBON 100 5% 1/4W
R506 1-247-807-31 CARBON 100 5% 1/4W
R507 1-247-807-31 CARBON 100 5% 1/4W
R508 1-247-807-31 CARBON 100 5% 1/4W
R509 1-247-807-31 CARBON 100 5% 1/4W
R510 1-247-807-31 CARBON 100 5% 1/4W
R512 1-249-413-11 CARBON 470 5% 1/4W F
R513 1-249-415-11 CARBON 680 5% 1/4W F
