Sony CDP-M7 - 3-3. Main Board and Connector Board Removal; 3-4. Base Unit Disassembly

— 8 —
3-3. MAIN BOARD AND CONNECTOR BOARD
3-4. BASE UNIT
1 Yoke bracket
3 Base unit block
2 Yoke bracket
4 Flat type wire (19 core)
CN302
2 Three screws
(BVTP 3X10)
1 Connector
(CN303)
5 Screw (BVTP 3X8)
6 Connector board
7 Flat type wire (8 CORE)
(CN702)
3 Main board
