CDP-S3
7
3-3. CD MECHANISM DECK (CDM63B-30BD60)
Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER
1
two screws
(case 3 TP2)
3
cover
2
screw
(BVTT3
×
6)
1
two screws
(case 3 TP2
)
3
four screws
(BVTP3
×
8)
1
wire (flat type) (21 core)
(CN301)
2
connecto
r
(CN701)
4
CD mechanism deck
(CDM63B-30BD60)
