CDP-S3
8
3-4. MAIN BOARD
3-5. FRONT PANEL SECTION
2
connector
(CN401)
1
wire (flat type) (21 core)
(CN301)
2
two connectors
(CN101, 102)
5
MAIN board
3
screw
(BVTP3
×
8)
4
lug
3
screw
(BVTP3
×
8)
2
connector
(CN701)
3
two screws
(BVTP3
×
8
)
2
three screws
(BVTP3
×
8)
3
two claws
1
connector
(CN401)
4
front panel section
3
claw
