– 57 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C415 1-130-892-00 FILM 0.015uF 5% 63V
C416 1-130-892-00 FILM 0.015uF 5% 63V
C417 1-136-818-11 FILM 0.0047uF 5% 100V
C418 1-136-818-11 FILM 0.0047uF 5% 100V
C419 1-136-252-00 FILM 0.0015uF 5% 100V
C420 1-136-252-00 FILM 0.0015uF 5% 100V
C421 1-136-818-11 FILM 0.0047uF 5% 100V
C422 1-136-814-11 FILM 0.001uF 5% 100V
C423 1-128-200-11 ELECT 47uF 20% 63V
C424 1-128-200-11 ELECT 47uF 20% 63V
C425 1-117-775-21 FILM 0.1uF 10% 250V
C500 1-128-201-11 ELECT 100uF 20% 63V
C501 1-136-850-11 FILM 0.1uF 5% 63V
C502 1-136-850-11 FILM 0.1uF 5% 63V
C503 1-136-850-11 FILM 0.1uF 5% 63V
C504 1-136-850-11 FILM 0.1uF 5% 63V
C505 1-136-850-11 FILM 0.1uF 5% 63V
C506 1-128-200-11 ELECT 47uF 20% 63V
C507 1-136-850-11 FILM 0.1uF 5% 63V
C508 1-136-850-11 FILM 0.1uF 5% 63V
C509 1-136-850-11 FILM 0.1uF 5% 63V
C510 1-136-850-11 FILM 0.1uF 5% 63V
C511 1-136-850-11 FILM 0.1uF 5% 63V
C514 1-130-973-00 FILM 0.022uF 5% 63V
C515 1-130-892-00 FILM 0.015uF 5% 63V
C516 1-130-892-00 FILM 0.015uF 5% 63V
C517 1-136-818-11 FILM 0.0047uF 5% 100V
C518 1-136-818-11 FILM 0.0047uF 5% 100V
C519 1-136-252-00 FILM 0.0015uF 5% 100V
C520 1-136-252-00 FILM 0.0015uF 5% 100V
C521 1-136-818-11 FILM 0.0047uF 5% 100V
C522 1-136-814-11 FILM 0.001uF 5% 100V
C523 1-128-200-11 ELECT 47uF 20% 63V
C524 1-128-200-11 ELECT 47uF 20% 63V
C525 1-117-775-21 FILM 0.1uF 10% 250V
C901 1-128-205-11 ELECT 1000uF 20% 63V
C902 1-128-205-11 ELECT 1000uF 20% 63V
C903 1-128-204-11 ELECT 470uF 20% 63V
C904 1-128-204-11 ELECT 470uF 20% 63V
C905 1-128-201-11 ELECT 100uF 20% 63V
C906 1-128-201-11 ELECT 100uF 20% 63V
C907 1-128-201-11 ELECT 100uF 20% 63V
C911 1-128-201-11 ELECT 100uF 20% 63V
C912 1-128-201-11 ELECT 100uF 20% 63V
C921 1-130-973-00 FILM 0.022uF 5% 63V
C922 1-136-818-11 FILM 0.0047uF 5% 100V
< CONNECTOR >
CN301 1-568-742-11 SOCKET, CONNECTOR 23P
CN901 1-564-506-11 PLUG, CONNECTOR 3P
* CN902 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D303 8-719-402-02 DIODE MA3091M-TX
D901 8-719-210-21 DIODE 11EQS04
D902 8-719-210-21 DIODE 11EQS04
D903 8-719-210-21 DIODE 11EQS04
D904 8-719-210-21 DIODE 11EQS04
< IC >
IC201 8-759-925-76 IC SN74HC08ANS
IC301 8-759-442-42 IC CXD8595Q
IC302 8-759-454-42 IC CXD2562Q-CS
IC303 8-759-083-94 IC TC7W74FU
IC401 8-759-371-51 IC CXA8042AS
IC402 8-759-296-74 IC AD712JR-REEL
IC403 8-759-296-74 IC AD712JR-REEL
IC501 8-759-371-51 IC CXA8042AS
IC502 8-759-296-74 IC AD712JR-REEL
IC503 8-759-296-74 IC AD712JR-REEL
IC901 8-759-231-58 IC TA7812S
IC902 8-759-245-86 IC TA7912S
IC903 8-759-231-53 IC TA7805S
IC904 8-759-604-90 IC M5F7907L
IC905 8-759-231-53 IC TA7805S
IC906 8-759-604-86 IC M5F7807L
IC907 8-759-231-53 IC TA7805S
< COIL >
L303 1-414-518-21 INDUCTOR 6.8uH
L305 1-414-518-21 INDUCTOR 6.8uH
L306 1-414-518-21 INDUCTOR 6.8uH
L401 1-414-518-21 INDUCTOR 6.8uH
< TRANSISTOR >
Q301 8-729-421-19 TRANSISTOR UN2213
Q302 8-729-424-08 TRANSISTOR UN2111
< RESISTOR >
R203 1-216-019-00 METAL CHIP 56 5% 1/10W
R206 1-216-021-00 METAL CHIP 68 5% 1/10W
R207 1-216-073-00 METAL CHIP 10K 5% 1/10W
R208 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R210 1-216-025-00 METAL GLAZE 100 5% 1/10W
R229 1-259-990-11 CARBON MELF 390 2% 1/8W
R231 1-259-990-11 CARBON MELF 390 2% 1/8W
R303 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R304 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R306 1-260-008-11 CARBON MELF 10K 2% 1/8W
R310 1-259-983-11 CARBON MELF 100 2% 1/8W
R312 1-216-041-00 METAL CHIP 470 5% 1/10W
R313 1-216-041-00 METAL CHIP 470 5% 1/10W
R314 1-216-041-00 METAL CHIP 470 5% 1/10W
R315 1-216-041-00 METAL CHIP 470 5% 1/10W
R316 1-216-041-00 METAL CHIP 470 5% 1/10W
R317 1-216-041-00 METAL CHIP 470 5% 1/10W
R351 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R352 1-216-025-00 METAL GLAZE 100 5% 1/10W
R353 1-216-001-00 METAL CHIP 10 5% 1/10W
R390 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R400 1-216-041-00 METAL CHIP 470 5% 1/10W
R401 1-259-989-11 CARBON MELF 330 2% 1/8W
R402 1-259-989-11 CARBON MELF 330 2% 1/8W
R403 1-259-989-11 CARBON MELF 330 2% 1/8W
R404 1-259-989-11 CARBON MELF 330 2% 1/8W
R405 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R406 1-259-971-11 CARBON MELF 10 2% 1/8W
R407 1-259-971-11 CARBON MELF 10 2% 1/8W
AUDIO
