Sony CDP-X3000 - Display Board Components; Digital Out SW Board Components

– 58 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R408 1-259-987-11 CARBON MELF 220 2% 1/8W
R409 1-259-989-11 CARBON MELF 330 2% 1/8W
R410 1-259-971-11 CARBON MELF 10 2% 1/8W
R411 1-259-990-11 CARBON MELF 390 2% 1/8W
R412 1-259-981-11 CARBON MELF 68 2% 1/8W
R413 1-259-971-11 CARBON MELF 10 2% 1/8W
R414 1-259-981-11 CARBON MELF 68 2% 1/8W
R415 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R416 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R417 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R418 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R419 1-259-995-11 CARBON MELF 1K 2% 1/8W
R420 1-259-995-11 CARBON MELF 1K 2% 1/8W
R421 1-259-995-11 CARBON MELF 1K 2% 1/8W
R422 1-260-028-11 CARBON MELF 470K 2% 1/8W
R423 1-259-971-11 CARBON MELF 10 2% 1/8W
R500 1-216-041-00 METAL CHIP 470 5% 1/10W
R501 1-259-989-11 CARBON MELF 330 2% 1/8W
R502 1-259-989-11 CARBON MELF 330 2% 1/8W
R503 1-259-989-11 CARBON MELF 330 2% 1/8W
R504 1-259-989-11 CARBON MELF 330 2% 1/8W
R505 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R506 1-259-971-11 CARBON MELF 10 2% 1/8W
R507 1-259-971-11 CARBON MELF 10 2% 1/8W
R508 1-259-987-11 CARBON MELF 220 2% 1/8W
R509 1-259-989-11 CARBON MELF 330 2% 1/8W
R510 1-259-971-11 CARBON MELF 10 2% 1/8W
R511 1-259-990-11 CARBON MELF 390 2% 1/8W
R512 1-259-981-11 CARBON MELF 68 2% 1/8W
R513 1-259-971-11 CARBON MELF 10 2% 1/8W
R514 1-259-981-11 CARBON MELF 68 2% 1/8W
R515 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R516 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R517 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R518 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
R519 1-259-995-11 CARBON MELF 1K 2% 1/8W
R520 1-259-995-11 CARBON MELF 1K 2% 1/8W
R521 1-259-995-11 CARBON MELF 1K 2% 1/8W
R522 1-260-028-11 CARBON MELF 470K 2% 1/8W
R523 1-259-971-11 CARBON MELF 10 2% 1/8W
R525 1-259-908-91 CARBON MELF 62 2% 1/8W
< COIL >
T201 1-409-594-11 COIL (WITH CORE)
< VIBRATOR >
X301 1-579-161-11 VIBRATOR, CRYSTAL (45MHz)
************************************************************
* 1-663-646-11 D OUT SW BOARD
***********
< CONNECTOR >
CN206 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S201 1-571-083-31 SWITCH, SLIDE (DIGITAL OUT)
************************************************************
AUDIO D OUT SW DIGITAL OUT DISPLAY
* 1-663-649-11 DIGITAL OUT BOARD
*****************
< CONNECTOR >
* CN204 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN205 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< IC >
IC202 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
< JACK >
J201 1-770-905-21 JACK, PIN 1P (DIGITAL OUT COAXIAL)
************************************************************
* A-4699-304-A DISPLAY BOARD, COMPLETE
************************
< CAPACITOR >
C801 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C803 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C804 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C810 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C811 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C812 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< CONNECTOR >
* CN801 1-564-518-11 PLUG, CONNECTOR 3P
* CN802 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN803 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN804 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN805 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN808 1-506-481-11 PIN, CONNECTOR 2P
< FLUORECENT INDICATOR >
FLD801 1-517-604-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-752-884-94 IC CXP82316-083Q
IC802 8-759-373-59 IC GP1U26XB
IC803 8-759-504-12 IC X24C01S
< TRANSISTOR >
Q801 8-729-421-22 TRANSISTOR UN2211
Q804 8-729-421-22 TRANSISTOR UN2211
< RESISTOR >
R801 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R802 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R804 1-216-073-00 METAL CHIP 10K 5% 1/10W
R805 1-216-073-00 METAL CHIP 10K 5% 1/10W
R816 1-216-037-00 METAL CHIP 330 5% 1/10W
R817 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R818 1-216-073-00 METAL CHIP 10K 5% 1/10W
R821 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R822 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R830 1-216-073-00 METAL CHIP 10K 5% 1/10W
R831 1-216-073-00 METAL CHIP 10K 5% 1/10W
