Sony CDP-X3000 - LED Board PWB Layout; Key Board Components; LED Board Components; AC SW Board Components

– 59 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X801 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
************************************************************
* A-4699-306-A KEY BOARD, COMPLETE
********************
< CAPACITOR >
C807 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C813 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C830 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN806 1-506-486-11 PIN, CONNECTOR 7P
< LED >
D801 8-719-032-86 LED SEL5420E (·)
D802 8-719-032-98 LED SEL5820A (∏)
< COIL >
L801 1-414-234-11 INDUCTOR, FERRITE BEAD
< TRANSISTOR >
Q802 8-729-421-22 TRANSISTOR UN2211
Q803 8-729-421-22 TRANSISTOR UN2211
< RESISTOR >
R803 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R806 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R807 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R808 1-216-045-00 METAL CHIP 680 5% 1/10W
R809 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R811 1-216-045-00 METAL CHIP 680 5% 1/10W
R812 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R813 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R814 1-216-029-00 METAL CHIP 150 5% 1/10W
R815 1-216-029-00 METAL CHIP 150 5% 1/10W
R835 1-216-049-11 METAL GLAZE 1K 5% 1/10W
< SWITCH >
S801 1-554-303-21 SWITCH, TACTILE (p)
S802 1-554-303-21 SWITCH, TACTILE (∏)
S803 1-554-303-21 SWITCH, TACTILE (·)
S804 1-554-303-21 SWITCH, TACTILE (+)
S805 1-554-303-21 SWITCH, TACTILE (=)
S806 1-554-303-21 SWITCH, TACTILE ())
S807 1-554-303-21 SWITCH, TACTILE (0)
S808 1-762-010-11 SWITCH, LEVER (IN/OUT SW)
************************************************************
* 1-663-650-12 LED BOARD
*********
< CAPACITOR >
C808 1-164-232-11 CERAMIC CHIP 0.01uF 50V
< LED >
D803 8-719-032-86 LED SEL5420E (POWER)
************************************************************
* 1-663-644-13 POWER BOARD
***********
< CAPACITOR >
C600 1-130-973-00 FILM 0.022uF 5% 63V
C601 1-136-818-11 FILM 0.0047uF 5% 100V
C605 1-128-198-11 ELECT 22uF 20% 63V
C606 1-124-724-11 ELECT 47uF 20% 50V
C607 1-128-200-11 ELECT 47uF 20% 63V
C608 1-136-850-11 FILM 0.1uF 5% 63V
C609 1-124-689-11 ELECT 1000uF 20% 16V
C610 1-124-689-11 ELECT 1000uF 20% 16V
C611 1-124-689-11 ELECT 1000uF 20% 16V
C612 1-124-689-11 ELECT 1000uF 20% 16V
C613 1-124-689-11 ELECT 1000uF 20% 16V
C614 1-124-689-11 ELECT 1000uF 20% 16V
C621 1-136-814-11 FILM 1000P 5% 100V
C622 1-106-351-00 MYLAR 2200PF 5% 200V
C624 1-104-645-11 CERAMIC 1uF 20% 50V
C625 1-136-816-11 FILM 0.0022uF 5% 100V
C650 1-130-973-00 FILM 0.022uF 5% 63V
C814 1-136-850-11 FILM 0.1uF 5% 63V
C815 1-136-850-11 FILM 0.1uF 5% 63V
< CONNECTOR >
* CN601 1-564-512-11 PLUG, CONNECTOR 9P
CN602 1-564-506-11 PLUG, CONNECTOR 3P
* CN603 1-564-507-11 PLUG, CONNECTOR 4P
* CN604 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D601 8-719-200-82 DIODE 11ES2
D602 8-719-200-82 DIODE 11ES2
D603 8-719-200-82 DIODE 11ES2
D604 8-719-200-82 DIODE 11ES2
D605 8-719-210-21 DIODE 11EQS04
D606 8-719-210-21 DIODE 11EQS04
D607 8-719-210-21 DIODE 11EQS04
D608 8-719-210-21 DIODE 11EQS04
D609 8-719-110-63 DIODE RD24ES-B3
D610 8-719-109-98 DIODE RD6.8ES-B3
DISPLAY KEY LED POWER
