Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< COIL >
L601 1-414-512-21 INDUCTOR 6.8uH
L602 1-424-122-11 FILTER, NOISE
L603 1-424-122-11 FILTER, NOISE
< TRANSISTOR >
Q601 8-729-019-65 TRANSISTOR 2SB1041T103
< RESISTOR >
! R601 1-212-869-00 FUSIBLE 33 5% 1/4W F
R602 1-247-843-11 CARBON 3.3K 5% 1/4W
R603 1-247-843-11 CARBON 3.3K 5% 1/4W
R604 1-249-433-11 CARBON 22K 5% 1/4W
R605 1-249-401-11 CARBON 47 5% 1/4W
R606 1-249-401-11 CARBON 47 5% 1/4W
R607 1-249-433-11 CARBON 22K 5% 1/4W
! R608 1-212-869-00 FUSIBLE 33 5% 1/4W F
************************************************************
* A-4699-302-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR >
C102 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C103 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C104 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C105 1-126-046-11 ELECT 3.3uF 20% 50V
C106 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C108 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C109 1-162-208-31 CERAMIC 24PF 5% 50V
C110 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C111 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C112 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C113 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C114 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C115 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C116 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C117 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C118 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C119 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C120 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C121 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C122 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C123 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C124 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C125 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C126 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C127 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C128 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C129 1-136-850-11 FILM 0.1uF 5% 63V
C130 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C131 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C132 1-128-198-11 ELECT 22uF 20% 63V
C133 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C134 1-136-850-11 FILM 0.1uF 5% 63V
C135 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C136 1-128-198-11 ELECT 22uF 20% 63V
C137 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C138 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C139 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C140 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C141 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C142 1-126-049-11 ELECT 22uF 20% 50V
C143 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C150 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C170 1-162-300-31 CERAMIC 0.01uF 20% 16V
C171 1-162-290-31 CERAMIC 470PF 10% 50V
C190 1-124-724-11 ELECT 47uF 20% 50V
C191 1-136-850-11 FILM 0.1uF 5% 63V
C192 1-136-850-11 FILM 0.1uF 5% 63V
C193 1-128-198-11 ELECT 22uF 20% 63V
C200 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C220 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C221 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C222 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C223 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN104 1-568-742-11 SOCKET, CONNECTOR 23P
CN105 1-564-506-11 PLUG, CONNECTOR 3P
* CN108 1-564-506-11 PLUG, CONNECTOR 3P
CN110 1-568-439-11 SOCKET, CONNECTOR 7P
* CN111 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN112 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN113 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
< IC >
IC103 8-759-636-16 IC M51957AL
IC104 8-759-233-64 IC TC74HCU04AF
IC105 8-752-369-78 IC CXD2545Q
IC106 8-759-071-79 IC BA6297AFP
IC107 8-752-072-45 IC CXA1821M-T6
< COIL >
L103 1-414-510-21 INDUCTOR 3.3uH
< TRANSISTOR >
Q101 8-729-421-19 TRANSISTOR UN2213
Q102 8-729-424-18 TRANSISTOR UN2113-TX
Q103 8-729-010-08 TRANSISTOR MSB710-R
Q104 8-729-010-08 TRANSISTOR MSB710-R
Q105 8-729-424-18 TRANSISTOR UN2113-TX
Q106 8-729-421-22 TRANSISTOR UN2211
Q107 8-729-424-08 TRANSISTOR UN2111
< RESISTOR >
R104 1-216-077-00 METAL CHIP 15K 5% 1/10W
R105 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R107 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R114 1-216-041-00 METAL CHIP 470 5% 1/10W
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
POWER SERVO
