Sony CDP-X3000 - Page 44

– 61 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R116 1-216-045-00 METAL CHIP 680 5% 1/10W
R119 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R123 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R124 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R125 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R126 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R127 1-216-033-00 METAL CHIP 220 5% 1/10W
R128 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R129 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R130 1-216-041-00 METAL CHIP 470 5% 1/10W
R131 1-216-041-00 METAL CHIP 470 5% 1/10W
R132 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R133 1-216-041-00 METAL CHIP 470 5% 1/10W
R134 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R135 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R138 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R139 1-216-073-00 METAL CHIP 10K 5% 1/10W
R140 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R141 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-025-00 METAL GLAZE 100 5% 1/10W
R144 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R145 1-216-073-00 METAL CHIP 10K 5% 1/10W
R146 1-216-073-00 METAL CHIP 10K 5% 1/10W
R147 1-216-073-00 METAL CHIP 10K 5% 1/10W
R148 1-216-073-00 METAL CHIP 10K 5% 1/10W
R149 1-216-073-00 METAL CHIP 10K 5% 1/10W
R150 1-216-085-00 METAL CHIP 33K 5% 1/10W
R151 1-216-073-00 METAL CHIP 10K 5% 1/10W
R152 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R153 1-216-073-00 METAL CHIP 10K 5% 1/10W
R154 1-216-073-00 METAL CHIP 10K 5% 1/10W
R155 1-216-073-00 METAL CHIP 10K 5% 1/10W
R156 1-216-073-00 METAL CHIP 10K 5% 1/10W
R157 1-216-073-00 METAL CHIP 10K 5% 1/10W
R158 1-216-073-00 METAL CHIP 10K 5% 1/10W
R159 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R160 1-216-077-00 METAL CHIP 15K 5% 1/10W
R161 1-216-077-00 METAL CHIP 15K 5% 1/10W
R162 1-216-073-00 METAL CHIP 10K 5% 1/10W
R163 1-216-073-00 METAL CHIP 10K 5% 1/10W
R164 1-216-073-00 METAL CHIP 10K 5% 1/10W
R165 1-216-073-00 METAL CHIP 10K 5% 1/10W
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
R167 1-216-081-00 METAL CHIP 22K 5% 1/10W
R168 1-216-295-00 CONDUCTOR, CHIP (2012)
R170 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R171 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-073-00 METAL CHIP 10K 5% 1/10W
R174 1-216-041-00 METAL CHIP 470 5% 1/10W
R175 1-216-079-00 METAL CHIP 18K 5% 1/10W
R176 1-216-101-00 METAL CHIP 150K 5% 1/10W
R177 1-216-101-00 METAL CHIP 150K 5% 1/10W
R178 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R179 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R180 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R181 1-216-073-00 METAL CHIP 10K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-101-00 METAL CHIP 150K 5% 1/10W
R184 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R185 1-216-113-00 METAL CHIP 470K 5% 1/10W
R186 1-216-073-00 METAL CHIP 10K 5% 1/10W
R188 1-216-003-11 METAL GLAZE 12 5% 1/10W
R189 1-216-001-00 METAL CHIP 10 5% 1/10W
R191 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R192 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R193 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R194 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R195 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R196 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R197 1-216-073-00 METAL CHIP 10K 5% 1/10W
R198 1-216-073-00 METAL CHIP 10K 5% 1/10W
R199 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R200 1-216-308-00 METAL GLAZE 4.7 5% 1/10W
R201 1-216-308-00 METAL GLAZE 4.7 5% 1/10W
R202 1-216-308-00 METAL GLAZE 4.7 5% 1/10W
R204 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R205 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R220 1-216-308-00 METAL GLAZE 4.7 5% 1/10W
R820 1-216-049-11 METAL GLAZE 1K 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-238-601-11 RES, ADJ, CARBON 22K
************************************************************
* 1-663-651-11 SLED BOARD
**********
< CONNECTOR >
* CN108 1-568-849-11 SOCKET, CONNECTOR 6P
* CN109 1-568-850-11 SOCKET, CONNECTOR 7P
************************************************************
* 1-663-652-11 SPINDLE BOARD
*************
< CONNECTOR >
CN107 1-691-065-31 HOUSING, CONNECTOR 6P
< SWITCH >
S151 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT IN)
S152 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT OUT)
************************************************************
SERVO SLED SPINDLE
